SUN HYDRAULICS
CXHCXDN
$91.04 USD
- SUN HYDRAULICS
- Material:CXHCXDN
- Model:CXHC-XDN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHCXDN (CXHCXDN) is a versatile and efficient hydraulic check valve designed for high-performance applications. This model operates as a standard 2-port check valve within a 3-port cavity configuration, where port 3 of the cartridge is blocked off. This design allows it to be used in circuits that require a check valve in existing three-port cavities, enhancing its utility in various hydraulic systems. The CXHCXDN features an impressive capacity of up to 80 gpm (320 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). It offers exceptional leakage control, with maximum leakage limited to less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and efficient operation. The valve's construction includes Sun's floating style design which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This model is equipped with a hex size of 1-1/4 inches (31.8 mm) and requires an installation torque between 150 -160 lbf-ft (203 -217 Nm). It uses Viton seals for enhanced durability and resistance against high temperatures and chemicals, making it suitable for challenging industrial environments. Overall, the Sun Hydraulics CXHCXDN check valve is an excellent choice for applications requiring reliable, low-leakage performance in a compact three-port cavity setup. Its robust design and high-quality construction ensure long-term reliability and efficiency in controlling fluid flow within hydraulic systems.
The Sun Hydraulics CXHCXDN (CXHCXDN) is a versatile and efficient hydraulic check valve designed for high-performance applications. This model operates as a standard 2-port check valve within a 3-port cavity configuration, where port 3 of the cartridge is blocked off. This design allows it to be used in circuits that require a check valve in existing three-port cavities, enhancing its utility in various hydraulic systems. The CXHCXDN features an impressive capacity of up to 80 gpm (320 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). It offers exceptional leakage control, with maximum leakage limited to less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and efficient operation. The valve's construction includes Sun's floating style design which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This model is equipped with a hex size of 1-1/4 inches (31.8 mm) and requires an installation torque between 150 -160 lbf-ft (203 -217 Nm). It uses Viton seals for enhanced durability and resistance against high temperatures and chemicals, making it suitable for challenging industrial environments. Overall, the Sun Hydraulics CXHCXDN check valve is an excellent choice for applications requiring reliable, low-leakage performance in a compact three-port cavity setup. Its robust design and high-quality construction ensure long-term reliability and efficiency in controlling fluid flow within hydraulic systems.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-17A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-017-006 |
