SUN HYDRAULICS
CXHCXDV
$98.98 USD
- SUN HYDRAULICS
- Material:CXHCXDV
- Model:CXHC-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXHCXDV (CXHCXDV) is a versatile check valve designed for hydraulic applications requiring reliable one-way flow in a three-port system. This model functions as a standard 2-port check valve but is uniquely fitted into a 3-port cavity, with the third port blocked off, making it ideal for retrofitting into existing systems without the need for additional modifications. The CXHCXDV valve is part of Sun Hydraulics' Series 3 and fits the T17A cavity type. With an impressive capacity to handle up to 80 gpm (320 L/min) and withstand maximum operating pressures of up to 5000 psi (350 bar), this valve is engineered for high-performance scenarios. It features extremely low leakage rates, less than one drop per minute (0.07 cc/min), ensuring efficient and clean operation. The construction of the CXHCXDV incorporates Sun\u2019s floating style design which minimizes internal part binding that could result from excessive installation torque or variations in cavity/cartridge machining. The valve has specific installation requirements with a hex size of 1-1/4 inches (31.8 mm) and an installation torque range between 150 - 160 lbf-ft (203 - 217 Nm). It also supports Viton seals, enhancing its durability and performance under varying environmental conditions. This product is direct-acting, which means it responds quickly to changes in pressure, making it both robust and stable for critical safety applications where preventing overpressure is essential.
The Sun Hydraulics CXHCXDV (CXHCXDV) is a versatile check valve designed for hydraulic applications requiring reliable one-way flow in a three-port system. This model functions as a standard 2-port check valve but is uniquely fitted into a 3-port cavity, with the third port blocked off, making it ideal for retrofitting into existing systems without the need for additional modifications. The CXHCXDV valve is part of Sun Hydraulics' Series 3 and fits the T17A cavity type. With an impressive capacity to handle up to 80 gpm (320 L/min) and withstand maximum operating pressures of up to 5000 psi (350 bar), this valve is engineered for high-performance scenarios. It features extremely low leakage rates, less than one drop per minute (0.07 cc/min), ensuring efficient and clean operation. The construction of the CXHCXDV incorporates Sun\u2019s floating style design which minimizes internal part binding that could result from excessive installation torque or variations in cavity/cartridge machining. The valve has specific installation requirements with a hex size of 1-1/4 inches (31.8 mm) and an installation torque range between 150 - 160 lbf-ft (203 - 217 Nm). It also supports Viton seals, enhancing its durability and performance under varying environmental conditions. This product is direct-acting, which means it responds quickly to changes in pressure, making it both robust and stable for critical safety applications where preventing overpressure is essential.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-17A |
| Series | 3 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-017-006 |
