SUN HYDRAULICS
CXIDLAN
$171.16 USD
- SUN HYDRAULICS
- Material:CXIDLAN
- Model:CXID-LAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIDLAN (CXIDLAN) is a high-performance hydraulic check valve designed for on-off circuit control, ensuring free flow from inlet port 2 to outlet port 1 while blocking flow in the reverse direction. This two-port check valve is tailored for applications requiring circuit correction in existing systems, particularly where manifold drillings may be incorrect. It features a sidetonose flow path from port 2 to port 1, although it is important to note that its capacity is approximately 30% less than models with a nosetoside flow path. The CXIDLAN model supports a maximum operating pressure of up to 5000 psi (350 bar) at both ports and can handle a flow capacity of up to 120 gpm (480 L/min). It boasts an extremely low leakage rate, with maximum valve leakage maintained at less than one drop per minute (0.07 cc/min). The valve's construction incorporates Sun's floating style design which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This model uses Viton seals for enhanced durability and chemical resistance, and has an installation torque range of 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). With its compact size and light weight of just 2.10 lb (0.95 kg), the CXIDLAN check valve offers an efficient and reliable solution for hydraulic circuit management in various applications, ensuring robust performance and longevity.
The Sun Hydraulics CXIDLAN (CXIDLAN) is a high-performance hydraulic check valve designed for on-off circuit control, ensuring free flow from inlet port 2 to outlet port 1 while blocking flow in the reverse direction. This two-port check valve is tailored for applications requiring circuit correction in existing systems, particularly where manifold drillings may be incorrect. It features a sidetonose flow path from port 2 to port 1, although it is important to note that its capacity is approximately 30% less than models with a nosetoside flow path. The CXIDLAN model supports a maximum operating pressure of up to 5000 psi (350 bar) at both ports and can handle a flow capacity of up to 120 gpm (480 L/min). It boasts an extremely low leakage rate, with maximum valve leakage maintained at less than one drop per minute (0.07 cc/min). The valve's construction incorporates Sun's floating style design which minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This model uses Viton seals for enhanced durability and chemical resistance, and has an installation torque range of 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). With its compact size and light weight of just 2.10 lb (0.95 kg), the CXIDLAN check valve offers an efficient and reliable solution for hydraulic circuit management in various applications, ensuring robust performance and longevity.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
