SUN HYDRAULICS
CXIDLCN
$168.18 USD
- SUN HYDRAULICS
- Material:CXIDLCN
- Model:CXID-LCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIDLCN (CXIDLCN) is a highly efficient check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a sidetonose check valve mechanism, allowing free flow from inlet port 2 to outlet port 1 while blocking reverse flow, making it an essential component for systems where manifold drillings might be incorrect. It operates under a maximum pressure of 5000 psi (350 bar) at both ports and offers a substantial capacity of up to 120 gpm (480 L/min). The CXIDLCN is engineered with Sun's floating style construction, which significantly reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This model is distinguished by its extremely low leakage rate, with less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. The check valve's robust design includes a T18A cavity and Series 4 compatibility, accommodating various hydraulic applications. Its installation requires specific torque settings between 350 - 375 lbf.ft (474 - 508 Nm) and utilizes a hex size of 1 5/8 inches (41.3 mm). Weighing at approximately 2.10 lb (0.95 kg), the CXIDLCN is compact yet powerful enough to support demanding hydraulic operations without performance degradation over time.
The Sun Hydraulics CXIDLCN (CXIDLCN) is a highly efficient check valve designed for hydraulic systems requiring reliable one-way flow control. This model features a sidetonose check valve mechanism, allowing free flow from inlet port 2 to outlet port 1 while blocking reverse flow, making it an essential component for systems where manifold drillings might be incorrect. It operates under a maximum pressure of 5000 psi (350 bar) at both ports and offers a substantial capacity of up to 120 gpm (480 L/min). The CXIDLCN is engineered with Sun's floating style construction, which significantly reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This model is distinguished by its extremely low leakage rate, with less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system efficiency. The check valve's robust design includes a T18A cavity and Series 4 compatibility, accommodating various hydraulic applications. Its installation requires specific torque settings between 350 - 375 lbf.ft (474 - 508 Nm) and utilizes a hex size of 1 5/8 inches (41.3 mm). Weighing at approximately 2.10 lb (0.95 kg), the CXIDLCN is compact yet powerful enough to support demanding hydraulic operations without performance degradation over time.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
