SUN HYDRAULICS
CXIDLFV
$176.62 USD
- SUN HYDRAULICS
- Material:CXIDLFV
- Model:CXID-LFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIDLFV (CXIDLFV) is a high-performance hydraulic check valve designed for efficient flow control in various hydraulic systems. This two-port sideto-nose check valve facilitates free flow from the inlet port 2 to the outlet port 1, while effectively blocking the reverse flow, ensuring optimal operation and preventing potential system damage. The CXIDLFV model operates under a maximum pressure of 5000 psi (350 bar) at both ports and boasts an impressive flow capacity of up to 120 gpm (480 L/min), making it suitable for high-flow applications. Notably, the CXIDLFV valve showcases extremely low leakage rates, with a maximum leakage less than one drop per minute (0.07 cc/min), which contributes to maintaining system integrity and reducing fluid loss. This model is built using Sun's floating style construction which minimizes internal part binding caused by excessive installation torque or cavity/cartridge machining variations. It also features a robust design capable of accepting considerable operational pressures without compromising performance. The physical specifications include a valve hex size of 1 5/8 inches (41.3 mm) and an installation torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). The unit weighs approximately 2.10 lbs (0.95 kg), facilitating easier handling and installation. Additionally, it utilizes Viton seals for enhanced durability and chemical resistance, further extending its usability across various hydraulic environments where reliability is paramount. Overall, the Sun Hydraulics CXIDLFV check valve is engineered for reliability and efficiency, suitable for applications requiring precise fluid control with minimal leakage to maintain system efficacy and safety.
The Sun Hydraulics CXIDLFV (CXIDLFV) is a high-performance hydraulic check valve designed for efficient flow control in various hydraulic systems. This two-port sideto-nose check valve facilitates free flow from the inlet port 2 to the outlet port 1, while effectively blocking the reverse flow, ensuring optimal operation and preventing potential system damage. The CXIDLFV model operates under a maximum pressure of 5000 psi (350 bar) at both ports and boasts an impressive flow capacity of up to 120 gpm (480 L/min), making it suitable for high-flow applications. Notably, the CXIDLFV valve showcases extremely low leakage rates, with a maximum leakage less than one drop per minute (0.07 cc/min), which contributes to maintaining system integrity and reducing fluid loss. This model is built using Sun's floating style construction which minimizes internal part binding caused by excessive installation torque or cavity/cartridge machining variations. It also features a robust design capable of accepting considerable operational pressures without compromising performance. The physical specifications include a valve hex size of 1 5/8 inches (41.3 mm) and an installation torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). The unit weighs approximately 2.10 lbs (0.95 kg), facilitating easier handling and installation. Additionally, it utilizes Viton seals for enhanced durability and chemical resistance, further extending its usability across various hydraulic environments where reliability is paramount. Overall, the Sun Hydraulics CXIDLFV check valve is engineered for reliability and efficiency, suitable for applications requiring precise fluid control with minimal leakage to maintain system efficacy and safety.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
