SUN HYDRAULICS
CXIDXEN
$160.24 USD
- SUN HYDRAULICS
- Material:CXIDXEN
- Model:CXID-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIDXEN (CXIDXEN) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model features a sidetonose check configuration, allowing free flow from port 2 to port 1 while blocking reverse flow, making it an essential component for circuit protection and efficiency. The CXIDXEN valve is engineered to fit a T18A cavity and is part of the Series 4 lineup, supporting a maximum capacity of 120 gpm (480 L/min). With its ability to withstand a maximum operating pressure of 5000 psi (350 bar), this valve is suitable for high-pressure systems. It boasts an extremely low leakage rate of less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system integrity. The valve's construction includes Sun's floating style design which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The CXIDXEN model has a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), it is robust yet compact enough for integration into various hydraulic setups without adding significant weight or bulk. The valve also uses Viton seals (990018006) for enhanced durability and chemical resistance, ensuring long-term performance even under harsh conditions.
The Sun Hydraulics CXIDXEN (CXIDXEN) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model features a sidetonose check configuration, allowing free flow from port 2 to port 1 while blocking reverse flow, making it an essential component for circuit protection and efficiency. The CXIDXEN valve is engineered to fit a T18A cavity and is part of the Series 4 lineup, supporting a maximum capacity of 120 gpm (480 L/min). With its ability to withstand a maximum operating pressure of 5000 psi (350 bar), this valve is suitable for high-pressure systems. It boasts an extremely low leakage rate of less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and enhanced system integrity. The valve's construction includes Sun's floating style design which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The CXIDXEN model has a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), it is robust yet compact enough for integration into various hydraulic setups without adding significant weight or bulk. The valve also uses Viton seals (990018006) for enhanced durability and chemical resistance, ensuring long-term performance even under harsh conditions.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
Show FAQ
