SUN HYDRAULICS
CXIDXEV
$166.69 USD
- SUN HYDRAULICS
- Material:CXIDXEV
- Model:CXID-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIDXEV (CXIDXEV) is a highly efficient and reliable check valve designed for hydraulic applications requiring robust flow control. This model features a side-to-nose free flow from port 2 to port 1, ensuring smooth operation in systems where reverse flow needs to be prevented. The CXIDXEV is built to accommodate a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of up to 120 gpm (480 L/min), making it suitable for high-pressure applications. The valve's construction includes Sun's floating style design which minimizes the risk of internal parts binding, a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This feature enhances the longevity and reliability of the valve under various operational conditions. Additionally, the CXIDXEV exhibits extremely low leakage rates, with maximum leakage specified at less than one drop per minute (0.07 cc/min), ensuring efficient performance and minimal fluid loss. With its compact design, weighing only 2.10 lbs (0.95 kg), and a hex size of 1 5/8 inches (41.3 mm), the CXIDXEV is easy to install with an installation torque range between 350 - 375 lbf ft (474 - 508 Nm). It uses Viton seals for enhanced durability against high temperatures and chemical exposure, ensuring consistent performance in demanding environments. This model is an ideal solution for circuit correction applications where manifold drillings are incorrect, serving as a circuit saver by providing reliable check functionality without extensive system modifications.
The Sun Hydraulics CXIDXEV (CXIDXEV) is a highly efficient and reliable check valve designed for hydraulic applications requiring robust flow control. This model features a side-to-nose free flow from port 2 to port 1, ensuring smooth operation in systems where reverse flow needs to be prevented. The CXIDXEV is built to accommodate a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of up to 120 gpm (480 L/min), making it suitable for high-pressure applications. The valve's construction includes Sun's floating style design which minimizes the risk of internal parts binding, a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. This feature enhances the longevity and reliability of the valve under various operational conditions. Additionally, the CXIDXEV exhibits extremely low leakage rates, with maximum leakage specified at less than one drop per minute (0.07 cc/min), ensuring efficient performance and minimal fluid loss. With its compact design, weighing only 2.10 lbs (0.95 kg), and a hex size of 1 5/8 inches (41.3 mm), the CXIDXEV is easy to install with an installation torque range between 350 - 375 lbf ft (474 - 508 Nm). It uses Viton seals for enhanced durability against high temperatures and chemical exposure, ensuring consistent performance in demanding environments. This model is an ideal solution for circuit correction applications where manifold drillings are incorrect, serving as a circuit saver by providing reliable check functionality without extensive system modifications.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
