SUN HYDRAULICS
CXIEXAV
$204.12 USD
- SUN HYDRAULICS
- Material:CXIEXAV
- Model:CXIE-XAV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIEXAV (CXIEXAV) is a uniquely designed check valve that operates as a standard 2-port check valve within a 3-port cavity, with the third port being blocked off. This configuration makes it ideal for applications requiring a check valve in existing three-port cavities. The CXIEXAV model is built to handle high pressures up to 5000 psi (350 bar) at ports 1 and 2, ensuring robust performance even under demanding conditions. The valve features Sun Hydraulics' floating style construction which minimizes the risk of internal parts binding. This is particularly important in scenarios where excessive installation torque or variations in cavity/cartridge machining might occur. With a capacity of handling up to 120 gpm (480 L/min), the CXIEXAV is suitable for high-flow systems. It also boasts an extremely low maximum leakage rate of less than one drop per minute (0.07 cc/min), making it an efficient choice for systems where fluid conservation and preventing contamination are critical. Physically, the valve has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque between 350 - 375 lbf-ft (474 - 508 Nm). Its compact design results in a weight of just 1.90 lbs (0.85 kg), facilitating easier handling and installation. For maintenance or repair, it uses a Viton seal kit, ensuring long-lasting performance even in corrosive environments as indicated by specific model code suffixes AP or LH for enhanced corrosion resistance. Overall, the Sun Hydraulics CXIEXAV check valve offers reliable performance with minimal leakage and high capacity, suitable for use in various hydraulic systems requiring precise fluid control within corrosive environments.
The Sun Hydraulics CXIEXAV (CXIEXAV) is a uniquely designed check valve that operates as a standard 2-port check valve within a 3-port cavity, with the third port being blocked off. This configuration makes it ideal for applications requiring a check valve in existing three-port cavities. The CXIEXAV model is built to handle high pressures up to 5000 psi (350 bar) at ports 1 and 2, ensuring robust performance even under demanding conditions. The valve features Sun Hydraulics' floating style construction which minimizes the risk of internal parts binding. This is particularly important in scenarios where excessive installation torque or variations in cavity/cartridge machining might occur. With a capacity of handling up to 120 gpm (480 L/min), the CXIEXAV is suitable for high-flow systems. It also boasts an extremely low maximum leakage rate of less than one drop per minute (0.07 cc/min), making it an efficient choice for systems where fluid conservation and preventing contamination are critical. Physically, the valve has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque between 350 - 375 lbf-ft (474 - 508 Nm). Its compact design results in a weight of just 1.90 lbs (0.85 kg), facilitating easier handling and installation. For maintenance or repair, it uses a Viton seal kit, ensuring long-lasting performance even in corrosive environments as indicated by specific model code suffixes AP or LH for enhanced corrosion resistance. Overall, the Sun Hydraulics CXIEXAV check valve offers reliable performance with minimal leakage and high capacity, suitable for use in various hydraulic systems requiring precise fluid control within corrosive environments.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 1.90 lb0,85 kg |
| Seal kit - Cartridge | Viton: 990-019-006 |
