SUN HYDRAULICS
CXIEXBV
$203.13 USD
- SUN HYDRAULICS
- Material:CXIEXBV
- Model:CXIE-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIEXBV (CXIEXBV) is a specialized hydraulic check valve designed for high-performance and reliability in fluid power applications. This valve operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port effectively blocked, making it particularly useful for adapting existing three-port systems without the need for extensive modifications. The CXIEXBV model features an innovative side-to-nose cheater check functionality, ensuring versatile integration into various hydraulic circuits. Engineered for durability and minimal leakage, the CXIEXBV guarantees an extremely low maximum leakage rate of less than one drop per minute (0.07 cc/min), making it an ideal choice for systems where fluid containment is critical. It can withstand pressures up to 5000 psi (350 bar) at ports 1 and 2, catering to high-pressure applications effortlessly. The valve\u2019s construction incorporates Sun's floating style design, which minimizes internal part misalignment and potential binding caused by installation torque or machining variations in the cavity/cartridge. The CXIEXBV is also built to resist corrosion, suitable for use in corrosive environments, indicated by specific model code suffixes like AP or LH. Its robust design specifications include a T19A cavity compatibility, Series 4 frame size, and a flow capacity of up to 120 gpm (480 L/min). Installation specifics include a hex size of 1-5/8 inches (41.3 mm) and an installation torque range of 350 - 375 lbf.ft (474 - 508 Nm). Weighing at approximately 1.90 lbs (0.85 kg), this valve maintains compactness and ease of handling during installation or maintenance processes.
The Sun Hydraulics CXIEXBV (CXIEXBV) is a specialized hydraulic check valve designed for high-performance and reliability in fluid power applications. This valve operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port effectively blocked, making it particularly useful for adapting existing three-port systems without the need for extensive modifications. The CXIEXBV model features an innovative side-to-nose cheater check functionality, ensuring versatile integration into various hydraulic circuits. Engineered for durability and minimal leakage, the CXIEXBV guarantees an extremely low maximum leakage rate of less than one drop per minute (0.07 cc/min), making it an ideal choice for systems where fluid containment is critical. It can withstand pressures up to 5000 psi (350 bar) at ports 1 and 2, catering to high-pressure applications effortlessly. The valve\u2019s construction incorporates Sun's floating style design, which minimizes internal part misalignment and potential binding caused by installation torque or machining variations in the cavity/cartridge. The CXIEXBV is also built to resist corrosion, suitable for use in corrosive environments, indicated by specific model code suffixes like AP or LH. Its robust design specifications include a T19A cavity compatibility, Series 4 frame size, and a flow capacity of up to 120 gpm (480 L/min). Installation specifics include a hex size of 1-5/8 inches (41.3 mm) and an installation torque range of 350 - 375 lbf.ft (474 - 508 Nm). Weighing at approximately 1.90 lbs (0.85 kg), this valve maintains compactness and ease of handling during installation or maintenance processes.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 1.90 lb0,85 kg |
| Seal kit - Cartridge | Viton: 990-019-006 |
