SUN HYDRAULICS
CXIEXCV
$201.14 USD
- SUN HYDRAULICS
- Material:CXIEXCV
- Model:CXIE-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIEXCV (CXIEXCV) is a versatile hydraulic check valve designed for high-performance and reliability in various applications. This model operates as a standard 2-port check valve within a 3-port cavity, with the third port effectively blocked, making it an ideal solution for circuits requiring a check valve in existing three-port configurations. The CXIEXCV supports substantial flow rates up to 120 gpm (480 L/min) and can handle maximum operating pressures of up to 5000 psi (350 bar), ensuring robust performance under demanding conditions. One of the standout features of the CXIEXCV is its exceptionally low leakage rate, which is less than one drop per minute (0.07 cc/min), providing an efficient system operation with minimal fluid loss. This model is constructed using corrosion-resistant materials, making it suitable for use in environments where corrosion could be a concern. Additionally, the valve incorporates Sun's floating style construction which minimizes internal parts binding that might occur due to excessive installation torque or variations in cavity/cartridge machining. The CXIEXCV uses a T19A cavity and belongs to the Series 4 line of Sun Hydraulics products. With a hex size of 1-5/8 in. (41.3 mm) and an installation torque range between 350 \u2013 375 lbf.ft (474 \u2013 508 Nm), this model ensures easy installation while maintaining secure and reliable operation. Weighing at approximately 1.90 lb (0.85 kg), it also includes options for Viton seals through the seal kit cartridge number 990019006, enhancing its versatility and adaptability across various hydraulic systems.
The Sun Hydraulics CXIEXCV (CXIEXCV) is a versatile hydraulic check valve designed for high-performance and reliability in various applications. This model operates as a standard 2-port check valve within a 3-port cavity, with the third port effectively blocked, making it an ideal solution for circuits requiring a check valve in existing three-port configurations. The CXIEXCV supports substantial flow rates up to 120 gpm (480 L/min) and can handle maximum operating pressures of up to 5000 psi (350 bar), ensuring robust performance under demanding conditions. One of the standout features of the CXIEXCV is its exceptionally low leakage rate, which is less than one drop per minute (0.07 cc/min), providing an efficient system operation with minimal fluid loss. This model is constructed using corrosion-resistant materials, making it suitable for use in environments where corrosion could be a concern. Additionally, the valve incorporates Sun's floating style construction which minimizes internal parts binding that might occur due to excessive installation torque or variations in cavity/cartridge machining. The CXIEXCV uses a T19A cavity and belongs to the Series 4 line of Sun Hydraulics products. With a hex size of 1-5/8 in. (41.3 mm) and an installation torque range between 350 \u2013 375 lbf.ft (474 \u2013 508 Nm), this model ensures easy installation while maintaining secure and reliable operation. Weighing at approximately 1.90 lb (0.85 kg), it also includes options for Viton seals through the seal kit cartridge number 990019006, enhancing its versatility and adaptability across various hydraulic systems.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 1.90 lb0,85 kg |
| Seal kit - Cartridge | Viton: 990-019-006 |
