SUN HYDRAULICS
CXIEXEV
$201.14 USD
- SUN HYDRAULICS
- Material:CXIEXEV
- Model:CXIE-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIEXEV (CXIEXEV) is a highly specialized hydraulic check valve designed for use in applications requiring a robust, low-leakage solution in corrosive environments. This model is part of the T19A cavity series and fits within the standard 4 series frame. The valve's unique construction allows it to function as a standard two-port check valve within a three-port cavity, with the third port blocked off, making it versatile for different hydraulic circuit designs. The CXIEXEV offers exceptional performance characteristics, including an impressive maximum flow capacity of 120 gpm (480 L/min) and can withstand operating pressures up to 5000 psi (350 bar). It features extremely low leakage rates, less than one drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. The valve's dimensions are tailored for easy integration, with a hex size of 1 5/8 inches (41.3 mm) and an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm). Constructed with corrosion-resistant materials, the CXIEXEV is suitable for harsh environments where reliability is crucial. Its innovative floating style design minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing its operational reliability and lifespan. This model weighs approximately 1.90 lbs (0.85 kg), making it robust yet manageable for system integration. Overall, the Sun Hydraulics CXIEXEV check valve is an excellent choice for engineers needing a reliable solution in existing three-port cavities or where corrosion resistance and low leakage are critical requirements.
The Sun Hydraulics CXIEXEV (CXIEXEV) is a highly specialized hydraulic check valve designed for use in applications requiring a robust, low-leakage solution in corrosive environments. This model is part of the T19A cavity series and fits within the standard 4 series frame. The valve's unique construction allows it to function as a standard two-port check valve within a three-port cavity, with the third port blocked off, making it versatile for different hydraulic circuit designs. The CXIEXEV offers exceptional performance characteristics, including an impressive maximum flow capacity of 120 gpm (480 L/min) and can withstand operating pressures up to 5000 psi (350 bar). It features extremely low leakage rates, less than one drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. The valve's dimensions are tailored for easy integration, with a hex size of 1 5/8 inches (41.3 mm) and an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm). Constructed with corrosion-resistant materials, the CXIEXEV is suitable for harsh environments where reliability is crucial. Its innovative floating style design minimizes the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing its operational reliability and lifespan. This model weighs approximately 1.90 lbs (0.85 kg), making it robust yet manageable for system integration. Overall, the Sun Hydraulics CXIEXEV check valve is an excellent choice for engineers needing a reliable solution in existing three-port cavities or where corrosion resistance and low leakage are critical requirements.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 1.90 lb0,85 kg |
| Seal kit - Cartridge | Viton: 990-019-006 |
