SUN HYDRAULICS
CXIEXFV
$203.13 USD
- SUN HYDRAULICS
- Material:CXIEXFV
- Model:CXIE-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIEXFV (CXIEXFV) is a specialized hydraulic check valve designed for high-performance applications requiring precise fluid control with minimal leakage. This model is a free-flow, side-to-nose cheater check valve that operates effectively as a standard 2-port check valve when installed in a 3-port cavity, with the third port blocked off. It is particularly useful in scenarios where a check valve needs to be incorporated into an existing three-port cavity configuration. The CXIEXFV can handle pressures up to 5000 psi (350 bar) at ports 1 and 2, making it suitable for high-pressure systems. The maximum flow capacity for this valve is impressive at 120 gpm (480 L/min), ensuring efficient operation in large-scale hydraulic systems. One of the key features of this model is its extremely low leakage rate, which does not exceed one drop per minute (0.07 cc/min), thereby enhancing system integrity and reducing fluid loss. Constructed to resist corrosion, the CXIEXFV incorporates Sun's floating style construction. This design minimizes the risk of internal parts binding which can occur due to excessive installation torque or variations in cavity/cartridge machining, thus ensuring reliable and consistent performance. The valve also requires specific installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm) and has a hex size of 1-5/8 inches (41.3 mm). Weighing at approximately 1.90 lbs (0.85 kg), it maintains a compact and manageable profile for various industrial applications. Additionally, this model uses Viton seals as indicated by its seal kit/cartridge number, ensuring compatibility with a wide range of fluids and maintaining good performance in diverse environmental conditions. The CXIEXFV's robust construction and advanced design make it an excellent choice for systems requiring reliable non-return functionality with the added flexibility of fitting into three-port cavities.
The Sun Hydraulics CXIEXFV (CXIEXFV) is a specialized hydraulic check valve designed for high-performance applications requiring precise fluid control with minimal leakage. This model is a free-flow, side-to-nose cheater check valve that operates effectively as a standard 2-port check valve when installed in a 3-port cavity, with the third port blocked off. It is particularly useful in scenarios where a check valve needs to be incorporated into an existing three-port cavity configuration. The CXIEXFV can handle pressures up to 5000 psi (350 bar) at ports 1 and 2, making it suitable for high-pressure systems. The maximum flow capacity for this valve is impressive at 120 gpm (480 L/min), ensuring efficient operation in large-scale hydraulic systems. One of the key features of this model is its extremely low leakage rate, which does not exceed one drop per minute (0.07 cc/min), thereby enhancing system integrity and reducing fluid loss. Constructed to resist corrosion, the CXIEXFV incorporates Sun's floating style construction. This design minimizes the risk of internal parts binding which can occur due to excessive installation torque or variations in cavity/cartridge machining, thus ensuring reliable and consistent performance. The valve also requires specific installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm) and has a hex size of 1-5/8 inches (41.3 mm). Weighing at approximately 1.90 lbs (0.85 kg), it maintains a compact and manageable profile for various industrial applications. Additionally, this model uses Viton seals as indicated by its seal kit/cartridge number, ensuring compatibility with a wide range of fluids and maintaining good performance in diverse environmental conditions. The CXIEXFV's robust construction and advanced design make it an excellent choice for systems requiring reliable non-return functionality with the added flexibility of fitting into three-port cavities.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 1.90 lb0,85 kg |
| Seal kit - Cartridge | Viton: 990-019-006 |
