SUN HYDRAULICS
CXIEXZN
$197.17 USD
- SUN HYDRAULICS
- Material:CXIEXZN
- Model:CXIE-XZN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXIEXZN (CXIEXZN) is a specialized hydraulic component designed for high-efficiency fluid control in a variety of applications. This model is a freeflow, side-to-nose cheater check valve that operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port effectively blocked. This unique design makes it suitable for integration into existing three-port cavities where only check valve functionality is required. The CXIEXZN valve supports flows up to 120 gpm (480 L/min) and can handle maximum operating pressures of up to 5000 psi (350 bar), making it robust for demanding applications. It features extremely low leakage rates, with less than one drop per minute (0.07 cc/min) ensuring efficient and reliable operation. The valve\u2019s construction includes Sun Hydraulics' floating style design which minimizes the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. With dimensions allowing for a hex size of 1 5/8 in. (41.3 mm) and an installation torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm), the CXIEXZN maintains a compact and durable profile weighing just 1.90 lbs (0.85 kg). It also supports Viton seals, enhancing its utility in corrosive environments typically challenging for standard valves. This model is particularly useful in hydraulic circuits requiring dependable backflow prevention without the spatial or structural capacity to alter existing port configurations significantly. Its high capacity and resistance to harsh conditions make it an excellent choice for sophisticated hydraulic systems needing precise fluid control under varying operational demands.
The Sun Hydraulics CXIEXZN (CXIEXZN) is a specialized hydraulic component designed for high-efficiency fluid control in a variety of applications. This model is a freeflow, side-to-nose cheater check valve that operates as a standard 2-port check valve within a 3-port cavity configuration, with the third port effectively blocked. This unique design makes it suitable for integration into existing three-port cavities where only check valve functionality is required. The CXIEXZN valve supports flows up to 120 gpm (480 L/min) and can handle maximum operating pressures of up to 5000 psi (350 bar), making it robust for demanding applications. It features extremely low leakage rates, with less than one drop per minute (0.07 cc/min) ensuring efficient and reliable operation. The valve\u2019s construction includes Sun Hydraulics' floating style design which minimizes the risk of internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. With dimensions allowing for a hex size of 1 5/8 in. (41.3 mm) and an installation torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm), the CXIEXZN maintains a compact and durable profile weighing just 1.90 lbs (0.85 kg). It also supports Viton seals, enhancing its utility in corrosive environments typically challenging for standard valves. This model is particularly useful in hydraulic circuits requiring dependable backflow prevention without the spatial or structural capacity to alter existing port configurations significantly. Its high capacity and resistance to harsh conditions make it an excellent choice for sophisticated hydraulic systems needing precise fluid control under varying operational demands.
Free-flow, side-to-nose cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 1.90 lb0,85 kg |
| Seal kit - Cartridge | Viton: 990-019-006 |
