SUN HYDRAULICS
CXJALCV
$174.63 USD
- SUN HYDRAULICS
- Material:CXJALCV
- Model:CXJA-LCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXJALCV (CXJALCV) is a highly efficient, two-port check valve designed for precise fluid control in hydraulic systems. The valve facilitates free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring reliable operation and minimal fluid loss with a maximum leakage rate of less than 1 drop per minute (0.07 cc/min). It is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports. This model is engineered with EPDM seals specifically for use with phosphate ester fluids; however, these seals are susceptible to damage if exposed to petroleum-based fluids, greases, and lubricants. The CXJALCV features Sun Hydraulics\u2019 floating style construction which minimizes potential internal part binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing its durability and performance consistency. The valve fits within a T18A cavity and belongs to Series 4, supporting up to 160 gpm (610 L/min) capacity. It requires an installation torque between 350 - 375 lbf ft (474 - 508 Nm) and has a hex size of 1-5/8 inches (41.3 mm). Weighing at approximately 2.10 lb (0.95 kg), this model ensures robust performance in various applications requiring precise fluid control and reliability under high-pressure conditions.
The Sun Hydraulics CXJALCV (CXJALCV) is a highly efficient, two-port check valve designed for precise fluid control in hydraulic systems. The valve facilitates free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring reliable operation and minimal fluid loss with a maximum leakage rate of less than 1 drop per minute (0.07 cc/min). It is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports. This model is engineered with EPDM seals specifically for use with phosphate ester fluids; however, these seals are susceptible to damage if exposed to petroleum-based fluids, greases, and lubricants. The CXJALCV features Sun Hydraulics\u2019 floating style construction which minimizes potential internal part binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing its durability and performance consistency. The valve fits within a T18A cavity and belongs to Series 4, supporting up to 160 gpm (610 L/min) capacity. It requires an installation torque between 350 - 375 lbf ft (474 - 508 Nm) and has a hex size of 1-5/8 inches (41.3 mm). Weighing at approximately 2.10 lb (0.95 kg), this model ensures robust performance in various applications requiring precise fluid control and reliability under high-pressure conditions.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 160 gpm610 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
