SUN HYDRAULICS
CXJAXFV
$168.67 USD
- SUN HYDRAULICS
- Material:CXJAXFV
- Model:CXJA-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXJAXFV (CXJAXFV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model facilitates free flow from inlet port 1 to outlet port 2 while preventing flow in the reverse direction, ensuring operational efficiency and safety in fluid power applications. The CXJAXFV is characterized by its extremely low leakage rate, with less than one drop per minute (0.07 cc/min) ensuring minimal fluid loss and maintaining system integrity. Constructed to handle a maximum operating pressure of 5000 psi (350 bar) at both ports, the CXJAXFV can accommodate flows up to 160 gpm (610 L/min), making it suitable for high-capacity systems. It features a T18A cavity and belongs to the Series 4 line of Sun Hydraulics' valves. Notably, this model incorporates Sun's floating style construction which reduces the risk of internal parts binding due to variations in installation torque or machining discrepancies. The valve is equipped with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based substances as they could degrade. For environments prone to corrosion, other variants of this model include corrosion-resistant options denoted by suffixes like AP or LH in the model code. With a weight of approximately 2.10 lbs (0.95 kg), and requiring an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm), the CXJAXFV is robust yet easy to handle during installation or maintenance procedures. Its design and construction make it an indispensable component in hydraulic circuits where unidirectional flow and leak prevention are critical.
The Sun Hydraulics CXJAXFV (CXJAXFV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model facilitates free flow from inlet port 1 to outlet port 2 while preventing flow in the reverse direction, ensuring operational efficiency and safety in fluid power applications. The CXJAXFV is characterized by its extremely low leakage rate, with less than one drop per minute (0.07 cc/min) ensuring minimal fluid loss and maintaining system integrity. Constructed to handle a maximum operating pressure of 5000 psi (350 bar) at both ports, the CXJAXFV can accommodate flows up to 160 gpm (610 L/min), making it suitable for high-capacity systems. It features a T18A cavity and belongs to the Series 4 line of Sun Hydraulics' valves. Notably, this model incorporates Sun's floating style construction which reduces the risk of internal parts binding due to variations in installation torque or machining discrepancies. The valve is equipped with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based substances as they could degrade. For environments prone to corrosion, other variants of this model include corrosion-resistant options denoted by suffixes like AP or LH in the model code. With a weight of approximately 2.10 lbs (0.95 kg), and requiring an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm), the CXJAXFV is robust yet easy to handle during installation or maintenance procedures. Its design and construction make it an indispensable component in hydraulic circuits where unidirectional flow and leak prevention are critical.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 160 gpm610 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
