SUN HYDRAULICS
CXJCXCV
$181.98 USD
- SUN HYDRAULICS
- Material:CXJCXCV
- Model:CXJC-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXJCXCV (CXJCXCV) is a specialized hydraulic check valve designed for high-efficiency fluid control in hydraulic systems. This valve functions as a standard 2-port check valve within a 3-port cavity, with the third port of the cartridge effectively blocked off. It is particularly useful in applications where a conventional check valve needs to be implemented within an existing three-port setup without additional modifications. Featuring Sun Hydraulics' distinctive floating style construction, the CXJCXCV minimizes potential internal part misalignment or binding that could arise from over-torquing during installation or from variations in cavity or cartridge machining. This design ensures reliable operation and extends the lifespan of the valve under rigorous conditions. The CXJCXCV boasts an impressive capacity of up to 120 gpm (480 L/min) and can handle maximum operating pressures up to 5000 psi (350 bar). The robust construction includes a valve hex size of 1-5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). It also features exceptionally low leakage rates, not exceeding one drop per minute (0.07 cc/min), which enhances system efficiency and reduces wastage. Ideal for high-pressure applications requiring precise fluid control and minimal leakage, the CXJCXCV is equipped with Viton seals (Seal kit: 990019006), ensuring compatibility with a wide range of hydraulic fluids and providing excellent resistance to high temperatures and chemicals. This check valve is an essential component for maintaining efficient, leak-free operations in complex hydraulic systems.
The Sun Hydraulics CXJCXCV (CXJCXCV) is a specialized hydraulic check valve designed for high-efficiency fluid control in hydraulic systems. This valve functions as a standard 2-port check valve within a 3-port cavity, with the third port of the cartridge effectively blocked off. It is particularly useful in applications where a conventional check valve needs to be implemented within an existing three-port setup without additional modifications. Featuring Sun Hydraulics' distinctive floating style construction, the CXJCXCV minimizes potential internal part misalignment or binding that could arise from over-torquing during installation or from variations in cavity or cartridge machining. This design ensures reliable operation and extends the lifespan of the valve under rigorous conditions. The CXJCXCV boasts an impressive capacity of up to 120 gpm (480 L/min) and can handle maximum operating pressures up to 5000 psi (350 bar). The robust construction includes a valve hex size of 1-5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). It also features exceptionally low leakage rates, not exceeding one drop per minute (0.07 cc/min), which enhances system efficiency and reduces wastage. Ideal for high-pressure applications requiring precise fluid control and minimal leakage, the CXJCXCV is equipped with Viton seals (Seal kit: 990019006), ensuring compatibility with a wide range of hydraulic fluids and providing excellent resistance to high temperatures and chemicals. This check valve is an essential component for maintaining efficient, leak-free operations in complex hydraulic systems.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-019-006 |
