SUN HYDRAULICS
CXJCXDV
$183.96 USD
- SUN HYDRAULICS
- Material:CXJCXDV
- Model:CXJC-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXJCXDV (CXJCXDV) is a high-performance check valve designed for hydraulic applications requiring reliable, low-leakage flow control in a three-port cavity configuration. This model operates as a standard 2-port check valve when the third port of the cartridge is blocked off, making it versatile for use in existing three-port systems. It is particularly useful for circuits where a robust check valve solution is needed without modifying existing cavities. Featuring Sun Hydraulics' innovative floating style construction, the CXJCXDV minimizes the risks of internal parts binding, which can occur due to over-torquing during installation or variations in cavity and cartridge machining. This design enhances the durability and reliability of the valve under various operational conditions. The valve supports a maximum flow capacity of 120 gpm (480 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure systems. The CXJCXDV also boasts an exceptionally low leakage rate, less than one drop per minute (0.07 cc/min), which is crucial for maintaining system efficiency and performance. The valve's specifications include a hex size of 1 5/8 inches (41.3 mm) and an installation torque range between 350 - 375 lbf\u00b7ft (474 - 508 Nm). For maintenance and repairs, it utilizes a Viton seal kit (990019006), ensuring long-term resilience against fluid and thermal degradation. This model's robust construction and precise engineering make it an optimal choice for demanding hydraulic applications where space constraints require the use of existing three-port cavities without sacrificing performance or reliability.
The Sun Hydraulics CXJCXDV (CXJCXDV) is a high-performance check valve designed for hydraulic applications requiring reliable, low-leakage flow control in a three-port cavity configuration. This model operates as a standard 2-port check valve when the third port of the cartridge is blocked off, making it versatile for use in existing three-port systems. It is particularly useful for circuits where a robust check valve solution is needed without modifying existing cavities. Featuring Sun Hydraulics' innovative floating style construction, the CXJCXDV minimizes the risks of internal parts binding, which can occur due to over-torquing during installation or variations in cavity and cartridge machining. This design enhances the durability and reliability of the valve under various operational conditions. The valve supports a maximum flow capacity of 120 gpm (480 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure systems. The CXJCXDV also boasts an exceptionally low leakage rate, less than one drop per minute (0.07 cc/min), which is crucial for maintaining system efficiency and performance. The valve's specifications include a hex size of 1 5/8 inches (41.3 mm) and an installation torque range between 350 - 375 lbf\u00b7ft (474 - 508 Nm). For maintenance and repairs, it utilizes a Viton seal kit (990019006), ensuring long-term resilience against fluid and thermal degradation. This model's robust construction and precise engineering make it an optimal choice for demanding hydraulic applications where space constraints require the use of existing three-port cavities without sacrificing performance or reliability.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-19A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-019-006 |
