SUN HYDRAULICS
CXKAXAV
$293.87 USD
- SUN HYDRAULICS
- Material:CXKAXAV
- Model:CXKA-XAV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXAV (CXKAXAV) is a high-performance check valve designed for hydraulic systems. This valve facilitates free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring efficient operation within hydraulic circuits. It is specifically engineered to fit Sun's T18A cavity, although using the T18AU cavity is recommended for achieving its full capacity of up to 240 gpm (900 L/min). The CXKAXAV can withstand a maximum operating pressure of 5000 psi (350 bar) at both ports. Constructed with durability and reliability in mind, this model features Sun's floating style construction which reduces the risk of internal parts binding due to variations in installation torque or cavity/cartridge machining. This design choice enhances the longevity and performance stability of the valve under diverse operational conditions. The CXKAXAV check valve is particularly noted for its extremely low leakage rate, less than one drop per minute (0.07 cc/min), making it an ideal choice for applications requiring stringent control over fluid loss. The valve is available with EPDM seals suitable for systems using phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. For environments prone to corrosion, variants of this model include corrosion-resistant options marked by suffixes AP or LH. Each cartridge weighs approximately 2.10 lbs (0.95 kg) and requires an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm). The valve also has a hex size of 1 5/8 in (41.3 mm), ensuring compatibility with standard tools for installation and maintenance.
The Sun Hydraulics CXKAXAV (CXKAXAV) is a high-performance check valve designed for hydraulic systems. This valve facilitates free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring efficient operation within hydraulic circuits. It is specifically engineered to fit Sun's T18A cavity, although using the T18AU cavity is recommended for achieving its full capacity of up to 240 gpm (900 L/min). The CXKAXAV can withstand a maximum operating pressure of 5000 psi (350 bar) at both ports. Constructed with durability and reliability in mind, this model features Sun's floating style construction which reduces the risk of internal parts binding due to variations in installation torque or cavity/cartridge machining. This design choice enhances the longevity and performance stability of the valve under diverse operational conditions. The CXKAXAV check valve is particularly noted for its extremely low leakage rate, less than one drop per minute (0.07 cc/min), making it an ideal choice for applications requiring stringent control over fluid loss. The valve is available with EPDM seals suitable for systems using phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. For environments prone to corrosion, variants of this model include corrosion-resistant options marked by suffixes AP or LH. Each cartridge weighs approximately 2.10 lbs (0.95 kg) and requires an installation torque between 350 - 375 lbf\u00b7ft (474 - 508 Nm). The valve also has a hex size of 1 5/8 in (41.3 mm), ensuring compatibility with standard tools for installation and maintenance.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
