SUN HYDRAULICS
CXKAXBV
$295.85 USD
- SUN HYDRAULICS
- Material:CXKAXBV
- Model:CXKA-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXBV (CXKAXBV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This valve permits free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring operational efficiency and safety. The CXKAXBV model is compatible with Sun's T18A cavity but achieves optimal performance when installed in the T18AU cavity, supporting a maximum capacity of 240 gpm (900 L/min). Constructed to handle a maximum operating pressure of 5000 psi (350 bar), this valve is suitable for high-pressure applications. It features exceptionally low leakage rates, less than one drop per minute (0.07 cc/min), minimizing fluid loss and maintaining system integrity. The valve's robust design includes EPDM seals specifically for use with phosphate ester fluids, although these seals must not be exposed to petroleum-based fluids as they could be damaged. The CXKAXBV incorporates Sun\u2019s floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing durability and reliability. With a hex size of 1 5/8 in (41.3 mm) and an installation torque requirement between 350 - 375 lbf.ft (474 - 508 Nm), it ensures a secure fit and easy installation. Weighing at approximately 2.10 lb (0.95 kg), this valve maintains a compact and manageable profile for various hydraulic setups.
The Sun Hydraulics CXKAXBV (CXKAXBV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This valve permits free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring operational efficiency and safety. The CXKAXBV model is compatible with Sun's T18A cavity but achieves optimal performance when installed in the T18AU cavity, supporting a maximum capacity of 240 gpm (900 L/min). Constructed to handle a maximum operating pressure of 5000 psi (350 bar), this valve is suitable for high-pressure applications. It features exceptionally low leakage rates, less than one drop per minute (0.07 cc/min), minimizing fluid loss and maintaining system integrity. The valve's robust design includes EPDM seals specifically for use with phosphate ester fluids, although these seals must not be exposed to petroleum-based fluids as they could be damaged. The CXKAXBV incorporates Sun\u2019s floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing durability and reliability. With a hex size of 1 5/8 in (41.3 mm) and an installation torque requirement between 350 - 375 lbf.ft (474 - 508 Nm), it ensures a secure fit and easy installation. Weighing at approximately 2.10 lb (0.95 kg), this valve maintains a compact and manageable profile for various hydraulic setups.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
