SUN HYDRAULICS
CXKAXDN
$289.40 USD
- SUN HYDRAULICS
- Material:CXKAXDN
- Model:CXKA-XDN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXDN (CXKAXDN) is a high-performance check valve designed for hydraulic applications requiring reliable, unidirectional flow control. This model operates optimally within Sun's T18A cavity but achieves its full capacity when installed in the T18AU cavity. With a substantial flow capacity of up to 240 gpm (900 L/min) and a maximum operating pressure of 5000 psi (350 bar), the CXKAXDN is well-suited for demanding hydraulic systems. This valve features Sun's innovative floating style construction, which reduces the risk of internal parts binding due to installation torque or machining variations in the cavity/cartridge. It also boasts an exceptionally low maximum leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring efficient performance and minimal fluid loss. The CXKAXDN is equipped with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. For environments prone to corrosion, variants of this model include corrosion-resistant configurations denoted by suffixes AP or LH in the model code. These versions are designed to extend the valve\u2019s lifespan and reliability in corrosive conditions. The valve itself has a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf.ft (474 \u2013 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), this robust valve integrates seamlessly into various hydraulic circuits, enhancing system integrity and performance stability across a range of industrial applications.
The Sun Hydraulics CXKAXDN (CXKAXDN) is a high-performance check valve designed for hydraulic applications requiring reliable, unidirectional flow control. This model operates optimally within Sun's T18A cavity but achieves its full capacity when installed in the T18AU cavity. With a substantial flow capacity of up to 240 gpm (900 L/min) and a maximum operating pressure of 5000 psi (350 bar), the CXKAXDN is well-suited for demanding hydraulic systems. This valve features Sun's innovative floating style construction, which reduces the risk of internal parts binding due to installation torque or machining variations in the cavity/cartridge. It also boasts an exceptionally low maximum leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring efficient performance and minimal fluid loss. The CXKAXDN is equipped with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. For environments prone to corrosion, variants of this model include corrosion-resistant configurations denoted by suffixes AP or LH in the model code. These versions are designed to extend the valve\u2019s lifespan and reliability in corrosive conditions. The valve itself has a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf.ft (474 \u2013 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), this robust valve integrates seamlessly into various hydraulic circuits, enhancing system integrity and performance stability across a range of industrial applications.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
