SUN HYDRAULICS
CXKAXDV
$295.85 USD
- SUN HYDRAULICS
- Material:CXKAXDV
- Model:CXKA-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXDV (CXKAXDV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This valve facilitates free flow from the inlet port 1 to the outlet port 2 while effectively blocking flow in the reverse direction, making it an essential component for a variety of hydraulic applications. The CXKAXDV operates optimally within Sun's T18A cavity but achieves full capacity when installed in a T18AU cavity, supporting up to 240 gpm/900 L/min of fluid. Engineered for durability and performance, the CXKAXDV can withstand maximum operating pressures of up to 5000 psi (350 bar) at both ports. It features extremely low leakage rates, less than 1 drop per minute (0.07 cc/min), ensuring efficient system operation and minimal fluid loss. The valve is configured with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as this can cause damage. For environments prone to corrosion, variants of this model include corrosion-resistant options identified by suffixes AP or LH in the model code. Additionally, the valve incorporates Sun\u2019s floating style construction which minimizes internal part binding due to excessive installation torque or variations in cavity/cartridge machining. This design enhances reliability and extends the operational lifespan of the valve. With a hex size of 1 5/8 in (41.3 mm) and an installation torque range of 350 - 375 lbf.ft (474 - 508 Nm), this robust check valve weighs approximately 2.10 lb (0.95 kg), facilitating ease of handling and installation in various hydraulic circuit configurations.
The Sun Hydraulics CXKAXDV (CXKAXDV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This valve facilitates free flow from the inlet port 1 to the outlet port 2 while effectively blocking flow in the reverse direction, making it an essential component for a variety of hydraulic applications. The CXKAXDV operates optimally within Sun's T18A cavity but achieves full capacity when installed in a T18AU cavity, supporting up to 240 gpm/900 L/min of fluid. Engineered for durability and performance, the CXKAXDV can withstand maximum operating pressures of up to 5000 psi (350 bar) at both ports. It features extremely low leakage rates, less than 1 drop per minute (0.07 cc/min), ensuring efficient system operation and minimal fluid loss. The valve is configured with EPDM seals specifically for use with phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as this can cause damage. For environments prone to corrosion, variants of this model include corrosion-resistant options identified by suffixes AP or LH in the model code. Additionally, the valve incorporates Sun\u2019s floating style construction which minimizes internal part binding due to excessive installation torque or variations in cavity/cartridge machining. This design enhances reliability and extends the operational lifespan of the valve. With a hex size of 1 5/8 in (41.3 mm) and an installation torque range of 350 - 375 lbf.ft (474 - 508 Nm), this robust check valve weighs approximately 2.10 lb (0.95 kg), facilitating ease of handling and installation in various hydraulic circuit configurations.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
