SUN HYDRAULICS
CXKAXEN
$287.42 USD
- SUN HYDRAULICS
- Material:CXKAXEN
- Model:CXKA-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXEN (CXKAXEN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. The valve ensures free flow from its inlet port 1 to outlet port 2 while blocking flow in the reverse direction, making it ideal for applications where unidirectional flow is crucial. This model operates effectively within Sun's standard T18A cavity but achieves optimal performance with the T18AU cavity, supporting a capacity of up to 240 gpm (900 L/min). The CXKAXEN is engineered to withstand pressures up to 5000 psi (350 bar) at both ports and features extremely low leakage rates, not exceeding 1 drop per minute (0.07 cc/min), ensuring efficient and secure operation in critical environments. Its robust design includes Sun's floating style construction which minimizes internal parts binding\u2014a common issue due to installation torque or cavity/cartridge machining variations. For applications involving corrosive substances, the CXKAXEN can be configured with EPDM seals specifically suited for phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. Additionally, the valve offers options for enhanced corrosion resistance with model code suffixes AP or LH. This check valve is also characterized by its significant durability and minimal maintenance requirements, making it a reliable component for various hydraulic systems. With a compact design weighing only 2.10 lbs (0.95 kg), and requiring an installation torque between 350 - 375 lbf.ft (474 - 508 Nm), the CXKAXEN combines high capacity performance with ease of installation in diverse operational settings.
The Sun Hydraulics CXKAXEN (CXKAXEN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. The valve ensures free flow from its inlet port 1 to outlet port 2 while blocking flow in the reverse direction, making it ideal for applications where unidirectional flow is crucial. This model operates effectively within Sun's standard T18A cavity but achieves optimal performance with the T18AU cavity, supporting a capacity of up to 240 gpm (900 L/min). The CXKAXEN is engineered to withstand pressures up to 5000 psi (350 bar) at both ports and features extremely low leakage rates, not exceeding 1 drop per minute (0.07 cc/min), ensuring efficient and secure operation in critical environments. Its robust design includes Sun's floating style construction which minimizes internal parts binding\u2014a common issue due to installation torque or cavity/cartridge machining variations. For applications involving corrosive substances, the CXKAXEN can be configured with EPDM seals specifically suited for phosphate ester fluids; however, these seals must not be exposed to petroleum-based fluids as they can cause damage. Additionally, the valve offers options for enhanced corrosion resistance with model code suffixes AP or LH. This check valve is also characterized by its significant durability and minimal maintenance requirements, making it a reliable component for various hydraulic systems. With a compact design weighing only 2.10 lbs (0.95 kg), and requiring an installation torque between 350 - 375 lbf.ft (474 - 508 Nm), the CXKAXEN combines high capacity performance with ease of installation in diverse operational settings.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
