SUN HYDRAULICS
CXKAXFN
$289.40 USD
- SUN HYDRAULICS
- Material:CXKAXFN
- Model:CXKA-XFN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXFN (CXKAXFN) is a high-performance check valve designed to facilitate free flow from the inlet port 1 to the outlet port 2 while blocking flow in the opposite direction. This model is specifically engineered to operate within Sun's standard T18A cavity, although for optimal performance and full capacity, the T18AU cavity is recommended. The CXKAXFN is capable of handling a maximum operating pressure of 5000 psi (350 bar) and offers a remarkably low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient and reliable operation in demanding applications. Constructed to minimize potential internal parts binding, this valve incorporates Sun's floating style construction which addresses issues that may arise from excessive installation torque or variations in cavity/cartridge machining. The valve's robust design also includes corrosion-resistant features suited for corrosive environments, indicated by specific model code suffixes AP or LH. The CXKAXFN check valve is designed with a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 - 375 lbf ft (474 - 508 Nm). Weighing at approximately 2.10 lb (0.95 kg), it maintains a compact and efficient profile suitable for various hydraulic applications where space and reliability are crucial. This model uses Viton seals for its cartridges, making it appropriate for systems utilizing phosphate ester fluids; however, it should not be exposed to petroleum-based fluids as they can damage the seals. Overall, the Sun Hydraulics CXKAXFN check valve provides a reliable solution for controlling fluid flow in hydraulic systems, ensuring both performance and durability across various operational conditions.
The Sun Hydraulics CXKAXFN (CXKAXFN) is a high-performance check valve designed to facilitate free flow from the inlet port 1 to the outlet port 2 while blocking flow in the opposite direction. This model is specifically engineered to operate within Sun's standard T18A cavity, although for optimal performance and full capacity, the T18AU cavity is recommended. The CXKAXFN is capable of handling a maximum operating pressure of 5000 psi (350 bar) and offers a remarkably low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient and reliable operation in demanding applications. Constructed to minimize potential internal parts binding, this valve incorporates Sun's floating style construction which addresses issues that may arise from excessive installation torque or variations in cavity/cartridge machining. The valve's robust design also includes corrosion-resistant features suited for corrosive environments, indicated by specific model code suffixes AP or LH. The CXKAXFN check valve is designed with a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 - 375 lbf ft (474 - 508 Nm). Weighing at approximately 2.10 lb (0.95 kg), it maintains a compact and efficient profile suitable for various hydraulic applications where space and reliability are crucial. This model uses Viton seals for its cartridges, making it appropriate for systems utilizing phosphate ester fluids; however, it should not be exposed to petroleum-based fluids as they can damage the seals. Overall, the Sun Hydraulics CXKAXFN check valve provides a reliable solution for controlling fluid flow in hydraulic systems, ensuring both performance and durability across various operational conditions.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
