SUN HYDRAULICS
CXKAXGN
$294.37 USD
- SUN HYDRAULICS
- Material:CXKAXGN
- Model:CXKA-XGN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXGN (CXKAXGN) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model operates optimally within Sun's T18AU cavity to achieve its maximum capacity of 240 gpm (900 L/min), although it can also fit in the standard T18A cavity at a reduced capacity. The CXKAXGN valve is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports 1 and 2, making it suitable for high-pressure systems. Engineered with EPDM seals, the CXKAXGN is specifically configured for use with phosphate ester fluids, ensuring durability and long service life in these environments. However, these seals are not compatible with petroleum-based fluids, which can cause damage. Featuring extremely low leakage rates, this model boasts a maximum valve leakage of less than one drop per minute (0.07 cc/min), highlighting its efficiency in maintaining system integrity. The valve's construction includes Sun's floating style design, which minimizes the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This feature enhances the reliability and performance consistency of the valve under varying operational conditions. For installation, the valve requires a hex size of 1-5/8 inches (41.3 mm) and an installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), the CXKAXGN is robust yet manageable in size for ease of handling and integration into hydraulic circuits.
The Sun Hydraulics CXKAXGN (CXKAXGN) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model operates optimally within Sun's T18AU cavity to achieve its maximum capacity of 240 gpm (900 L/min), although it can also fit in the standard T18A cavity at a reduced capacity. The CXKAXGN valve is capable of handling a maximum operating pressure of 5000 psi (350 bar) at both ports 1 and 2, making it suitable for high-pressure systems. Engineered with EPDM seals, the CXKAXGN is specifically configured for use with phosphate ester fluids, ensuring durability and long service life in these environments. However, these seals are not compatible with petroleum-based fluids, which can cause damage. Featuring extremely low leakage rates, this model boasts a maximum valve leakage of less than one drop per minute (0.07 cc/min), highlighting its efficiency in maintaining system integrity. The valve's construction includes Sun's floating style design, which minimizes the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This feature enhances the reliability and performance consistency of the valve under varying operational conditions. For installation, the valve requires a hex size of 1-5/8 inches (41.3 mm) and an installation torque between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), the CXKAXGN is robust yet manageable in size for ease of handling and integration into hydraulic circuits.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
