SUN HYDRAULICS
CXKAXGV
$300.82 USD
- SUN HYDRAULICS
- Material:CXKAXGV
- Model:CXKA-XGV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXKAXGV (CXKAXGV) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model is crafted to fit perfectly into Sun's standard T18A cavity, although using the T18AU cavity is recommended for achieving its full flow capacity of 240 gpm (900 L/min). The CXKAXGV supports a maximum operating pressure of 5000 psi (350 bar) and ensures minimal leakage, with a maximum rate of less than one drop per minute (0.07 cc/min), thereby offering exceptional performance in maintaining system integrity. This valve features corrosion-resistant construction suitable for harsh environments, with specific configurations available for systems using phosphate ester fluids through EPDM seals. It is critical to note that these EPDM seals must not be exposed to petroleum-based fluids as they can cause damage. The design incorporates Sun's floating style construction which reduces the risk of internal parts binding\u2014a common issue that can arise due to excessive installation torque or variations in cavity/cartridge machining. Additionally, the CXKAXGV model is robustly built with a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf-ft (474 \u2013 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), this valve maintains a compact and efficient profile suitable for various hydraulic applications where space and reliability are critical considerations.
The Sun Hydraulics CXKAXGV (CXKAXGV) is a high-performance check valve designed for hydraulic systems requiring reliable, unidirectional flow control. This model is crafted to fit perfectly into Sun's standard T18A cavity, although using the T18AU cavity is recommended for achieving its full flow capacity of 240 gpm (900 L/min). The CXKAXGV supports a maximum operating pressure of 5000 psi (350 bar) and ensures minimal leakage, with a maximum rate of less than one drop per minute (0.07 cc/min), thereby offering exceptional performance in maintaining system integrity. This valve features corrosion-resistant construction suitable for harsh environments, with specific configurations available for systems using phosphate ester fluids through EPDM seals. It is critical to note that these EPDM seals must not be exposed to petroleum-based fluids as they can cause damage. The design incorporates Sun's floating style construction which reduces the risk of internal parts binding\u2014a common issue that can arise due to excessive installation torque or variations in cavity/cartridge machining. Additionally, the CXKAXGV model is robustly built with a hex size of 1 5/8 inches (41.3 mm) and requires an installation torque between 350 \u2013 375 lbf-ft (474 \u2013 508 Nm). Weighing at approximately 2.10 lbs (0.95 kg), this valve maintains a compact and efficient profile suitable for various hydraulic applications where space and reliability are critical considerations.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 240 gpm900 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
