SUN HYDRAULICS
CXZAXBN
$20.35 USD
- SUN HYDRAULICS
- Material:CXZAXBN
- Model:CXZA-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXZAXBN (CXZAXBN) is a high-performance check valve designed for hydraulic applications requiring reliable one-way flow and leakage control. This model allows free flow from the inlet port 1 to the outlet port 2 while effectively blocking flow in the opposite direction, ensuring operational consistency and safety. The valve is characterized by its exceptionally low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), making it an ideal choice for systems where minimal fluid loss is critical. The CXZAXBN can withstand pressures up to 5000 psi (350 bar) at both ports, demonstrating robust performance under high-pressure conditions. It features Sun's proprietary floating style construction which reduces the risk of internal parts binding\u2014a common issue that can arise due to excessive installation torque or variations in cavity/cartridge machining. With a modest flow capacity of 1 gpm (4 L/min), this model is well-suited for small to medium-scale applications. It incorporates a .188 inch (approximately 3/16 inch) internal hex size for installation, with specified torque settings ranging between 100 and 120 lbf\u00b7in (11 - 14 Nm). The unit\u2019s compact design and light weight (.20 lb or approximately 0.10 kg) facilitate easy handling and installation in space-constrained environments. This check valve uses Viton seals, ensuring compatibility with a wide range of hydraulic fluids and maintaining integrity under various temperature conditions. Its direct-acting operation mode provides quick response times and reliable performance, essential for maintaining system efficiency and preventing overpressure situations. The Sun Hydraulics CXZAXBN is a versatile component suitable for numerous hydraulic applications where precision and reliability are paramount.
The Sun Hydraulics CXZAXBN (CXZAXBN) is a high-performance check valve designed for hydraulic applications requiring reliable one-way flow and leakage control. This model allows free flow from the inlet port 1 to the outlet port 2 while effectively blocking flow in the opposite direction, ensuring operational consistency and safety. The valve is characterized by its exceptionally low leakage rate, which does not exceed 1 drop per minute (0.07 cc/min), making it an ideal choice for systems where minimal fluid loss is critical. The CXZAXBN can withstand pressures up to 5000 psi (350 bar) at both ports, demonstrating robust performance under high-pressure conditions. It features Sun's proprietary floating style construction which reduces the risk of internal parts binding\u2014a common issue that can arise due to excessive installation torque or variations in cavity/cartridge machining. With a modest flow capacity of 1 gpm (4 L/min), this model is well-suited for small to medium-scale applications. It incorporates a .188 inch (approximately 3/16 inch) internal hex size for installation, with specified torque settings ranging between 100 and 120 lbf\u00b7in (11 - 14 Nm). The unit\u2019s compact design and light weight (.20 lb or approximately 0.10 kg) facilitate easy handling and installation in space-constrained environments. This check valve uses Viton seals, ensuring compatibility with a wide range of hydraulic fluids and maintaining integrity under various temperature conditions. Its direct-acting operation mode provides quick response times and reliable performance, essential for maintaining system efficiency and preventing overpressure situations. The Sun Hydraulics CXZAXBN is a versatile component suitable for numerous hydraulic applications where precision and reliability are paramount.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Due to size constraints, this valve has a .188 (3/16) inch internal hex. There is no metric equivalent.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-382A |
| Series | Z |
| Capacity | 1 gpm4 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Internal Hex Size | 3/16 in.5 mm |
| Valve Installation Torque | 100 - 120 lbf in.11 - 14 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-382-006 |
