SUN HYDRAULICS
DBAMTCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DBAMTCV (DBAMTCV) is a versatile, manually operated directional control valve designed for pilot flow applications in hydraulic systems. This 2-position, 3-way valve comes in two spool configurations: normally open from port 1 to 2 and normally open from port 1 to 3. It features Sun's unique TwistLock manual override mechanism, suitable primarily for intermittent and infrequent use, ensuring reliable manual control when automatic operation is not feasible. The DBAMTCV model is engineered with a hardened spool and sleeve to ensure consistent operation, low leakage rates, and superior wear characteristics. It utilizes Sun\u2019s floating style construction which helps prevent internal parts binding that can occur due to excessive installation torque or variations in cavity/cartridge machining. This design enhances the durability and longevity of the valve under varying operational conditions. For manual operation, the DBAMTCV offers multiple control options including momentary-twist (option T), detent-lock (option L), and dual-operation (option D). These options provide flexibility in control, allowing operators to either momentarily shift the valve or maintain it in a mechanically detented position as required by specific applications. The manual control assembly itself is robust, designed for about 10,000 cycles before requiring replacement - which can be done easily in the field without needing to remove the cartridge from its manifold. Key specifications include a maximum operating pressure of 5000 psi (350 bar), a flow capacity of .25 gpm (1 L/min), and maximum valve leakage at high pressure is minimal at about 10 drops/min. The valve\u2019s compact design features a hex size of 7/8 inches (22.2 mm) and weighs approximately .40 lb (0.20 kg), making it easy to integrate into various hydraulic systems without significant spatial or weight concerns.
