SUN HYDRAULICS
DCCBDCN
$175.43 USD
- SUN HYDRAULICS
- Material:DCCBDCN
- Model:DCCB-DCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBDCN (DCCBDCN) is a high-performance, two-position, detented, 4-way directional cartridge valve designed for robust hydraulic systems. This model features a unique six-port configuration that allows up to three different spool options, enhancing its versatility in various applications. Each port, including the x and y pilot ports (port 5 and port 6), can withstand pressures up to 5000 psi (350 bar), making it suitable for high-pressure operations. The DCCBDCN valve is engineered with a hardened spool and sleeve which not only ensures low leakage rates but also provides excellent wear characteristics, prolonging the life of the valve under demanding conditions. The incorporation of Sun's floating style construction minimizes internal parts binding, which can occur due to excessive installation torque or variations in cavity/cartridge machining. With a flow capacity ranging from 10 to 13 gpm (40 to 50 L/min), this valve is capable of handling significant fluid volumes efficiently. It also features a maximum operating pressure of 5000 psi (350 bar) and maintains tight control over leakage, with maximum valve leakage specified at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). Additional specifications include a pilot volume displacement of .05 in\u00b3 (0.82 cc), and the model requires an installation torque between 30 - 35 lbf ft (41 - 47 Nm). The compact design results in a lightweight model weighing just .40 lb (0.20 kg). For maintenance, it uses a Viton seal kit designated as part number: 990061006. Overall, the Sun Hydraulics DCCBDCN offers reliable performance and flexibility for hydraulic systems requiring precise control under high-pressure conditions.
The Sun Hydraulics DCCBDCN (DCCBDCN) is a high-performance, two-position, detented, 4-way directional cartridge valve designed for robust hydraulic systems. This model features a unique six-port configuration that allows up to three different spool options, enhancing its versatility in various applications. Each port, including the x and y pilot ports (port 5 and port 6), can withstand pressures up to 5000 psi (350 bar), making it suitable for high-pressure operations. The DCCBDCN valve is engineered with a hardened spool and sleeve which not only ensures low leakage rates but also provides excellent wear characteristics, prolonging the life of the valve under demanding conditions. The incorporation of Sun's floating style construction minimizes internal parts binding, which can occur due to excessive installation torque or variations in cavity/cartridge machining. With a flow capacity ranging from 10 to 13 gpm (40 to 50 L/min), this valve is capable of handling significant fluid volumes efficiently. It also features a maximum operating pressure of 5000 psi (350 bar) and maintains tight control over leakage, with maximum valve leakage specified at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). Additional specifications include a pilot volume displacement of .05 in\u00b3 (0.82 cc), and the model requires an installation torque between 30 - 35 lbf ft (41 - 47 Nm). The compact design results in a lightweight model weighing just .40 lb (0.20 kg). For maintenance, it uses a Viton seal kit designated as part number: 990061006. Overall, the Sun Hydraulics DCCBDCN offers reliable performance and flexibility for hydraulic systems requiring precise control under high-pressure conditions.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
