SUN HYDRAULICS
DCCBDXN
$180.39 USD
- SUN HYDRAULICS
- Material:DCCBDXN
- Model:DCCB-DXN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBDXN (DCCBDXN) is a robust and versatile hydraulic directional control valve, ideal for various demanding applications. This model is a two-position, detented, 4-way directional cartridge valve with six ports, which includes the flexibility of up to three different spool options depending on specific system requirements. Each port, including the x and y pilot ports (port 5 and port 6), can withstand pressures up to 5000 psi (350 bar). The DCCBDXN offers a flow capacity ranging between 10 to 13 gpm (40 to 50 L/min), making it suitable for a broad range of flow rates. Designed with durability in mind, the valve features a hardened spool and sleeve that ensure low leakage rates and excellent wear characteristics over time. Furthermore, it incorporates Sun\u2019s floating style construction which minimizes internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. Leakage per path is meticulously detailed in the technical specifications to ensure reliable performance. Additional specifications include a maximum operating pressure of 5000 psi (350 bar), maximum valve leakage at 110 SUS (24 cSt) being only 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), and pilot volume displacement of .05 in\u00b3 (0.82 cc). The unit requires an installation torque between 30 to 35 lbf\u00b7ft (41 to 47 Nm) and has a hex size of 7/8 inches (22.2 mm). Weighing just .40 lb (0.20 kg), this model is compact yet powerful for its size. The DCCBDXN uses Viton seals for enhanced performance under varying conditions, ensuring reliability and longevity in hydraulic systems where high pressure and flow precision are critical.
The Sun Hydraulics DCCBDXN (DCCBDXN) is a robust and versatile hydraulic directional control valve, ideal for various demanding applications. This model is a two-position, detented, 4-way directional cartridge valve with six ports, which includes the flexibility of up to three different spool options depending on specific system requirements. Each port, including the x and y pilot ports (port 5 and port 6), can withstand pressures up to 5000 psi (350 bar). The DCCBDXN offers a flow capacity ranging between 10 to 13 gpm (40 to 50 L/min), making it suitable for a broad range of flow rates. Designed with durability in mind, the valve features a hardened spool and sleeve that ensure low leakage rates and excellent wear characteristics over time. Furthermore, it incorporates Sun\u2019s floating style construction which minimizes internal parts binding\u2014a common issue that can arise from excessive installation torque or variations in cavity/cartridge machining. Leakage per path is meticulously detailed in the technical specifications to ensure reliable performance. Additional specifications include a maximum operating pressure of 5000 psi (350 bar), maximum valve leakage at 110 SUS (24 cSt) being only 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), and pilot volume displacement of .05 in\u00b3 (0.82 cc). The unit requires an installation torque between 30 to 35 lbf\u00b7ft (41 to 47 Nm) and has a hex size of 7/8 inches (22.2 mm). Weighing just .40 lb (0.20 kg), this model is compact yet powerful for its size. The DCCBDXN uses Viton seals for enhanced performance under varying conditions, ensuring reliability and longevity in hydraulic systems where high pressure and flow precision are critical.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
