SUN HYDRAULICS
DCCBDXV
$191.31 USD
- SUN HYDRAULICS
- Material:DCCBDXV
- Model:DCCB-DXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBDXV (DCCBDXV) is a high-performance, two-position, detented 4-way directional cartridge valve, featuring a six-port configuration that can be customized with up to three different spool options. This model is specifically designed for robust and efficient hydraulic system operations, delivering a flow capacity of 10-13 gpm (40-50 L/min) and accommodating a maximum operating pressure of 5000 psi (350 bar). Each port on the valve, including the X and Y pilot ports (port 5 and port 6), supports this high-pressure rating, ensuring versatile application in demanding environments. The DCCBDXV valve boasts a hardened spool and sleeve which significantly reduce spool leakage rates while providing exceptional wear characteristics. This durability is further enhanced by Sun Hydraulics\u2019 floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The valve's design includes a T61A cavity and adheres to Series 1 specifications. For ease of installation, the valve features a hex size of 7/8 inches (22.2 mm) and requires an installation torque of 30-35 lbf ft (41-47 Nm). Weighing just 0.40 lb (0.20 kg), it is lightweight yet sturdy enough for both mobile and industrial applications. The maximum valve leakage at 110 SUS (24 cSt) is specified at 2 in\u00b3/min per 1000 psi (30 cc/min per 70 bar), ensuring efficient operation with minimal fluid loss. Additionally, pilot volume displacement stands at approximately .05 in\u00b3 (0.82 cc). For maintenance or repairs, Viton seal kits are available under part number: 990061006.
The Sun Hydraulics DCCBDXV (DCCBDXV) is a high-performance, two-position, detented 4-way directional cartridge valve, featuring a six-port configuration that can be customized with up to three different spool options. This model is specifically designed for robust and efficient hydraulic system operations, delivering a flow capacity of 10-13 gpm (40-50 L/min) and accommodating a maximum operating pressure of 5000 psi (350 bar). Each port on the valve, including the X and Y pilot ports (port 5 and port 6), supports this high-pressure rating, ensuring versatile application in demanding environments. The DCCBDXV valve boasts a hardened spool and sleeve which significantly reduce spool leakage rates while providing exceptional wear characteristics. This durability is further enhanced by Sun Hydraulics\u2019 floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The valve's design includes a T61A cavity and adheres to Series 1 specifications. For ease of installation, the valve features a hex size of 7/8 inches (22.2 mm) and requires an installation torque of 30-35 lbf ft (41-47 Nm). Weighing just 0.40 lb (0.20 kg), it is lightweight yet sturdy enough for both mobile and industrial applications. The maximum valve leakage at 110 SUS (24 cSt) is specified at 2 in\u00b3/min per 1000 psi (30 cc/min per 70 bar), ensuring efficient operation with minimal fluid loss. Additionally, pilot volume displacement stands at approximately .05 in\u00b3 (0.82 cc). For maintenance or repairs, Viton seal kits are available under part number: 990061006.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
