SUN HYDRAULICS
DCCBXCN
$172.45 USD
- SUN HYDRAULICS
- Material:DCCBXCN
- Model:DCCB-XCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBXCN (DCCBXCN) is a high-performance hydraulic directional control valve, ideal for advanced fluid power applications. This two-position, detented, 4-way directional cartridge valve features a six-port configuration that can be tailored with up to three different spool options, enhancing its versatility in various hydraulic systems. Each port, including the x and y pilot ports (port 5 and port 6), can withstand a maximum operating pressure of 5000 psi (350 bar), ensuring robust performance even under high-pressure conditions. The DCCBXCN is designed with a hardened spool and sleeve which not only minimizes leakage\u2014listed technically for each path\u2014but also provides excellent wear characteristics, thus extending the valve's operational life. The incorporation of Sun's floating style construction reduces the risk of internal parts binding, which could result from excessive installation torque or variations in cavity/cartridge machining. This model operates within a flow capacity range of 10 to 13 gpm (40 to 50 L/min) and features a maximum valve leakage at 110 SUS (24 cSt) of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). It also has a pilot volume displacement of .05 in\u00b3 (0.82 cc). For installation, the valve requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 - 35 lbf\u00b7ft (41 -47 Nm). Weighing just .40 lb (0.20 kg), this model is both compact and easy to handle during installation or maintenance processes. The recommended seal kit for this cartridge is Viton: 990061006. Overall, the Sun Hydraulics DCCBXCN offers superior control for directing fluid within hydraulic systems, making it an essential component for ensuring efficient and reliable machine operation.
The Sun Hydraulics DCCBXCN (DCCBXCN) is a high-performance hydraulic directional control valve, ideal for advanced fluid power applications. This two-position, detented, 4-way directional cartridge valve features a six-port configuration that can be tailored with up to three different spool options, enhancing its versatility in various hydraulic systems. Each port, including the x and y pilot ports (port 5 and port 6), can withstand a maximum operating pressure of 5000 psi (350 bar), ensuring robust performance even under high-pressure conditions. The DCCBXCN is designed with a hardened spool and sleeve which not only minimizes leakage\u2014listed technically for each path\u2014but also provides excellent wear characteristics, thus extending the valve's operational life. The incorporation of Sun's floating style construction reduces the risk of internal parts binding, which could result from excessive installation torque or variations in cavity/cartridge machining. This model operates within a flow capacity range of 10 to 13 gpm (40 to 50 L/min) and features a maximum valve leakage at 110 SUS (24 cSt) of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). It also has a pilot volume displacement of .05 in\u00b3 (0.82 cc). For installation, the valve requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 - 35 lbf\u00b7ft (41 -47 Nm). Weighing just .40 lb (0.20 kg), this model is both compact and easy to handle during installation or maintenance processes. The recommended seal kit for this cartridge is Viton: 990061006. Overall, the Sun Hydraulics DCCBXCN offers superior control for directing fluid within hydraulic systems, making it an essential component for ensuring efficient and reliable machine operation.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
