SUN HYDRAULICS
DCCBXHN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBXHN (DCCBXHN) is a robust two-position, detented, 4-way directional cartridge valve designed for hydraulic systems. Featuring a T61A cavity and Series 1 compatibility, this model ensures versatility in application. With the capacity to handle flow rates from 10 to 13 gpm (40 to 50 L/min) and a maximum operating pressure of 5000 psi (350 bar), it is suitable for various high-pressure operations. The valve's ports, including the pilot ports port 5 and port 6, all accommodate the same maximum pressure, enhancing its reliability in complex circuits. Each pathway of the DCCBXHN exhibits minimal leakage at a rate of only 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), thanks to its hardened spool and sleeve that not only reduce wear but also maintain consistent performance over time. The floating style construction of the valve minimizes internal parts binding\u2014a common issue with installation torque or cavity/cartridge machining variations\u2014ensuring smooth operation and extended life. This model requires a hex size of 7/8 inch (22.2 mm) for installation with recommended torque settings between 30 - 35 lbf\u00b7ft (41 - 47 Nm). Weighing just .40 lb (0.20 kg), it provides a compact yet powerful solution for directing fluid within hydraulic systems efficiently. Additionally, it uses Viton seals for enhanced durability against high temperatures and various chemicals, ensuring reliable sealing under diverse operating conditions.
