SUN HYDRAULICS
DCCBXHV
$192.31 USD
- SUN HYDRAULICS
- Material:DCCBXHV
- Model:DCCB-XHV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBXHV (DCCBXHV) is a high-performance, two-position, detented, 4-way directional cartridge valve designed for robust hydraulic system applications. This model boasts a 6-port configuration that can be tailored with up to three different spool options depending on the specific requirements of the application. Each port on this valve, including the x and y pilot ports (port 5 and port 6), can handle pressures up to 5000 psi (350 bar), making it suitable for high-pressure operations. The DCCBXHV features a hardened spool and sleeve which ensure low spool leakage rates and superior wear characteristics, essential for maintaining system efficiency and longevity. The valve's design incorporates Sun\u2019s floating style construction which minimizes internal part binding\u2014a common issue resulting from excessive installation torque or variations in cavity/cartridge machining. This model is specified to operate within a flow capacity range of 10 to 13 gpm (40 to 50 L/min), with maximum valve leakage at a rate of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). It also includes detailed specifications such as a pilot volume displacement of .05 in\u00b3 (0.82 cc), a valve hex size of 7/8 in. (22.2 mm), and an installation torque range of 30 -35 lbf\u00b7ft (41 -47 Nm). Weighing just .40 lb (0.20 kg), the DCCBXHV combines lightweight construction with robust performance capabilities. Furthermore, this model uses Viton seals for enhanced temperature and chemical resistance, ensuring reliable performance across various operating conditions. The Sun Hydraulics DCCBXHV is an exemplary choice for those needing a reliable and versatile hydraulic control valve in demanding applications.
The Sun Hydraulics DCCBXHV (DCCBXHV) is a high-performance, two-position, detented, 4-way directional cartridge valve designed for robust hydraulic system applications. This model boasts a 6-port configuration that can be tailored with up to three different spool options depending on the specific requirements of the application. Each port on this valve, including the x and y pilot ports (port 5 and port 6), can handle pressures up to 5000 psi (350 bar), making it suitable for high-pressure operations. The DCCBXHV features a hardened spool and sleeve which ensure low spool leakage rates and superior wear characteristics, essential for maintaining system efficiency and longevity. The valve's design incorporates Sun\u2019s floating style construction which minimizes internal part binding\u2014a common issue resulting from excessive installation torque or variations in cavity/cartridge machining. This model is specified to operate within a flow capacity range of 10 to 13 gpm (40 to 50 L/min), with maximum valve leakage at a rate of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). It also includes detailed specifications such as a pilot volume displacement of .05 in\u00b3 (0.82 cc), a valve hex size of 7/8 in. (22.2 mm), and an installation torque range of 30 -35 lbf\u00b7ft (41 -47 Nm). Weighing just .40 lb (0.20 kg), the DCCBXHV combines lightweight construction with robust performance capabilities. Furthermore, this model uses Viton seals for enhanced temperature and chemical resistance, ensuring reliable performance across various operating conditions. The Sun Hydraulics DCCBXHV is an exemplary choice for those needing a reliable and versatile hydraulic control valve in demanding applications.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
