SUN HYDRAULICS
DCCBXXN
$177.41 USD
- SUN HYDRAULICS
- Material:DCCBXXN
- Model:DCCB-XXN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBXXN (DCCBXXN) is a high-performance hydraulic directional control valve, designed for robust and efficient operation in demanding applications. This two-position, detented, 4-way directional cartridge valve boasts a 6-port configuration that can be tailored with up to three different spool options to meet specific operational requirements. Each of the valve's ports, including the X and Y pilot ports (port 5 and port 6), can handle a maximum operating pressure of 5000 psi (350 bar), ensuring reliable functionality under high-pressure conditions. The DCCBXXN is engineered with a hardened spool and sleeve which not only reduce spool leakage rates but also enhance wear characteristics, contributing to the valve\u2019s longevity and consistent performance. It features Sun Hydraulics' distinctive floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model is compatible with T61A cavity specifications and falls under the Series 1 category from Sun Hydraulics. It offers a flow capacity ranging from 10 to 13 gpm (40 to 50 L/min) and exhibits maximum valve leakage at a rate of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). The DCCBXXN also supports pilot volume displacement of approximately .05 in\u00b3 (0.82 cc). For installation, it requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 \u2013 35 lbf ft (41 \u2013 47 Nm). The model itself weighs about .40 lb (0.20 kg), making it compact yet sturdy for various hydraulic systems. Additionally, it utilizes Viton seals for enhanced chemical resistance and durability under diverse operating conditions.
The Sun Hydraulics DCCBXXN (DCCBXXN) is a high-performance hydraulic directional control valve, designed for robust and efficient operation in demanding applications. This two-position, detented, 4-way directional cartridge valve boasts a 6-port configuration that can be tailored with up to three different spool options to meet specific operational requirements. Each of the valve's ports, including the X and Y pilot ports (port 5 and port 6), can handle a maximum operating pressure of 5000 psi (350 bar), ensuring reliable functionality under high-pressure conditions. The DCCBXXN is engineered with a hardened spool and sleeve which not only reduce spool leakage rates but also enhance wear characteristics, contributing to the valve\u2019s longevity and consistent performance. It features Sun Hydraulics' distinctive floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This model is compatible with T61A cavity specifications and falls under the Series 1 category from Sun Hydraulics. It offers a flow capacity ranging from 10 to 13 gpm (40 to 50 L/min) and exhibits maximum valve leakage at a rate of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). The DCCBXXN also supports pilot volume displacement of approximately .05 in\u00b3 (0.82 cc). For installation, it requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 \u2013 35 lbf ft (41 \u2013 47 Nm). The model itself weighs about .40 lb (0.20 kg), making it compact yet sturdy for various hydraulic systems. Additionally, it utilizes Viton seals for enhanced chemical resistance and durability under diverse operating conditions.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
