SUN HYDRAULICS
DCCBXXV
$188.33 USD
- SUN HYDRAULICS
- Material:DCCBXXV
- Model:DCCB-XXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCBXXV (DCCBXXV) is a high-performance hydraulic valve specifically designed for robust and precise fluid control in demanding applications. This two-position, detented, 4-way directional cartridge valve features six ports, including a supply port (port 1) and pilot ports (port 5 and port 6), all of which can handle up to 5000 psi or 350 bar. The valve offers multiple spool options that influence its capacity, generally ranging between 10 to 13 gpm (40 to 50 L/min). Crafted with a hardened spool and sleeve, the DCCBXXV ensures low leakage rates and exceptional wear characteristics, maintaining consistent performance even under harsh conditions. The design incorporates Sun\u2019s floating style construction, which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This model is suitable for various hydraulic systems where precise control of fluid direction and flow is necessary. With a maximum operating pressure of 5000 psi and a maximum valve leakage at 110 SUS (24 cSt) of only 2 in\u00b3/min at 1000 psi, it demonstrates efficient operation with minimal fluid loss. The valve also features pilot volume displacement of approximately .05 in\u00b3 (0.82 cc), ensuring responsive control. Additional specifications include a hex size for the valve at 7/8 in (22.2 mm) and an installation torque requirement between 30-35 lbf\u00b7ft (41-47 Nm). The model weighs about .40 lb (0.20 kg), making it compact yet sturdy for industrial use. For maintenance or repair, a Viton seal kit is available under part number: 990061006. This cartridge is housed within the T61A cavity and belongs to series 1, reflecting its standardized design compatible with various hydraulic setups requiring reliable directional control.
The Sun Hydraulics DCCBXXV (DCCBXXV) is a high-performance hydraulic valve specifically designed for robust and precise fluid control in demanding applications. This two-position, detented, 4-way directional cartridge valve features six ports, including a supply port (port 1) and pilot ports (port 5 and port 6), all of which can handle up to 5000 psi or 350 bar. The valve offers multiple spool options that influence its capacity, generally ranging between 10 to 13 gpm (40 to 50 L/min). Crafted with a hardened spool and sleeve, the DCCBXXV ensures low leakage rates and exceptional wear characteristics, maintaining consistent performance even under harsh conditions. The design incorporates Sun\u2019s floating style construction, which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This model is suitable for various hydraulic systems where precise control of fluid direction and flow is necessary. With a maximum operating pressure of 5000 psi and a maximum valve leakage at 110 SUS (24 cSt) of only 2 in\u00b3/min at 1000 psi, it demonstrates efficient operation with minimal fluid loss. The valve also features pilot volume displacement of approximately .05 in\u00b3 (0.82 cc), ensuring responsive control. Additional specifications include a hex size for the valve at 7/8 in (22.2 mm) and an installation torque requirement between 30-35 lbf\u00b7ft (41-47 Nm). The model weighs about .40 lb (0.20 kg), making it compact yet sturdy for industrial use. For maintenance or repair, a Viton seal kit is available under part number: 990061006. This cartridge is housed within the T61A cavity and belongs to series 1, reflecting its standardized design compatible with various hydraulic setups requiring reliable directional control.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
