SUN HYDRAULICS
DCCDXCV
$163.61 USD
- SUN HYDRAULICS
- Material:DCCDXCV
- Model:DCCD-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCDXCV (DCCDXCV) is a high-performance hydraulic valve designed for robust and precise fluid control in various applications. This two-position, detented, 4-way directional cartridge valve features a six-port configuration that can be tailored with up to three different spool options depending on specific system requirements. The DCCDXCV operates efficiently with a supply port at port 3, and all ports are capable of handling pressures up to 5000 psi (350 bar). Key specifications include a flow capacity ranging from 10 to 13 gpm (40 to 50 L/min), making it suitable for medium flow rate applications. The minimum pilot pressure required to shift the valve is set at 175 psi (12 bar), ensuring reliable operation under varying conditions. This model also boasts maximum operating pressure capabilities of up to 5000 psi (350 bar). The DCCDXCV is engineered with hardened spool and sleeve components which significantly reduce spool leakage rates while enhancing wear characteristics. This durability is further supported by Sun's floating style construction, which minimizes internal part binding\u2014commonly caused by excessive installation torque or cavity/cartridge machining inconsistencies. For installation, the valve requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 - 35 lbf ft (41 - 47 Nm). The model's weight is minimal at approximately .40 lb (0.20 kg), facilitating easier handling and integration into existing systems without significant weight implications. Overall, the Sun Hydraulics DCCDXCV offers reliable performance and adaptability for dynamic hydraulic systems requiring precise directional control of fluid flow under high-pressure conditions.
The Sun Hydraulics DCCDXCV (DCCDXCV) is a high-performance hydraulic valve designed for robust and precise fluid control in various applications. This two-position, detented, 4-way directional cartridge valve features a six-port configuration that can be tailored with up to three different spool options depending on specific system requirements. The DCCDXCV operates efficiently with a supply port at port 3, and all ports are capable of handling pressures up to 5000 psi (350 bar). Key specifications include a flow capacity ranging from 10 to 13 gpm (40 to 50 L/min), making it suitable for medium flow rate applications. The minimum pilot pressure required to shift the valve is set at 175 psi (12 bar), ensuring reliable operation under varying conditions. This model also boasts maximum operating pressure capabilities of up to 5000 psi (350 bar). The DCCDXCV is engineered with hardened spool and sleeve components which significantly reduce spool leakage rates while enhancing wear characteristics. This durability is further supported by Sun's floating style construction, which minimizes internal part binding\u2014commonly caused by excessive installation torque or cavity/cartridge machining inconsistencies. For installation, the valve requires a hex size of 7/8 in. (22.2 mm) and an installation torque between 30 - 35 lbf ft (41 - 47 Nm). The model's weight is minimal at approximately .40 lb (0.20 kg), facilitating easier handling and integration into existing systems without significant weight implications. Overall, the Sun Hydraulics DCCDXCV offers reliable performance and adaptability for dynamic hydraulic systems requiring precise directional control of fluid flow under high-pressure conditions.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- The pilot ports, 5 and 6, are positively sealed from the work ports.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 175 psi12 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
