SUN HYDRAULICS
DCCDXXV
$168.57 USD
- SUN HYDRAULICS
- Material:DCCDXXV
- Model:DCCD-XXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCCDXXV (DCCDXXV) is a robust and versatile two-position, detented, 4-way directional cartridge valve. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity ranging between 10 to 13 gpm (40 to 50 L/min), this valve is designed to handle demanding hydraulic control applications efficiently. The DCCDXXV features six ports including supply port (port 3) and pilot ports (ports 5 and 6), all capable of withstanding the maximum pressure rating. This model is distinguished by its hardened spool and sleeve which ensure low leakage rates and superior wear characteristics, essential for maintaining system integrity and performance over time. The valve's design incorporates Sun's floating style construction which helps prevent internal parts binding that might otherwise occur due to excessive installation torque or variations in cavity/cartridge machining. The minimum pilot pressure required to shift the valve is relatively low at 175 psi (12 bar), making it suitable for various pilot-operated applications where precise control of fluid direction is needed. Additionally, the DCCDXXV has a specified maximum valve leakage rate at 110 SUS (24 cSt) of approximately 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), ensuring efficient operation with minimal fluid loss. Installation specifications include a valve hex size of 7/8 inches (22.2 mm) and an installation torque requirement between 30 -35 lbf\u00b7ft (41 -47 Nm). The model\u2019s weight is notably light at approximately 0.40 lb (0.20 kg), facilitating easier handling and integration into various systems. This directional cartridge uses Viton seals for enhanced temperature and chemical resistance, further broadening its application range across different hydraulic systems.
The Sun Hydraulics DCCDXXV (DCCDXXV) is a robust and versatile two-position, detented, 4-way directional cartridge valve. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity ranging between 10 to 13 gpm (40 to 50 L/min), this valve is designed to handle demanding hydraulic control applications efficiently. The DCCDXXV features six ports including supply port (port 3) and pilot ports (ports 5 and 6), all capable of withstanding the maximum pressure rating. This model is distinguished by its hardened spool and sleeve which ensure low leakage rates and superior wear characteristics, essential for maintaining system integrity and performance over time. The valve's design incorporates Sun's floating style construction which helps prevent internal parts binding that might otherwise occur due to excessive installation torque or variations in cavity/cartridge machining. The minimum pilot pressure required to shift the valve is relatively low at 175 psi (12 bar), making it suitable for various pilot-operated applications where precise control of fluid direction is needed. Additionally, the DCCDXXV has a specified maximum valve leakage rate at 110 SUS (24 cSt) of approximately 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), ensuring efficient operation with minimal fluid loss. Installation specifications include a valve hex size of 7/8 inches (22.2 mm) and an installation torque requirement between 30 -35 lbf\u00b7ft (41 -47 Nm). The model\u2019s weight is notably light at approximately 0.40 lb (0.20 kg), facilitating easier handling and integration into various systems. This directional cartridge uses Viton seals for enhanced temperature and chemical resistance, further broadening its application range across different hydraulic systems.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- The pilot ports, 5 and 6, are positively sealed from the work ports.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 10 - 13 gpm40 - 50 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 175 psi12 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-061-006 |
