SUN HYDRAULICS
DCDDXCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCDDXCV (DCDDXCV) is a high-performance two-position, detented, 4-way directional cartridge valve designed for robust hydraulic system applications. This model features a 6-port configuration that can be tailored with up to three different spool options, enhancing its adaptability for various operational requirements. The DCDDXCV operates efficiently with a maximum operating pressure of 5000 psi (350 bar) across all ports, including the X and Y pilot ports (port 5 and port 6), ensuring broad compatibility with high-pressure systems. The valve's design incorporates hardened spool and sleeve to reduce spool leakage rates significantly while providing excellent wear characteristics. This durability is further supported by Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The DCDDXCV also boasts a capacity ranging from 20 to 30 gpm (80 to 120 L/min), depending on the spool type used, making it suitable for a wide range of flow rates. For operational control, the minimum pilot pressure required to shift the valve is set at 150 psi (10.5 bar). The model also features specific leakage rates per path provided in its technical data for precise maintenance planning. Additional practical specifications include a pilot volume displacement of .12 in^3 (2.0 cc), valve hex size of 1-1/8 in. (28.6 mm), and an installation torque requirement between 45-50 lbf-ft (61-68 Nm). Weighing just .80 lb (0.35 kg), the DCDDXCV provides an efficient solution for system designers seeking reliable and adaptable hydraulic control components.
