SUN HYDRAULICS
DCDDXXN

Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.

• All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
• Leakage listed in technical data is for each path.
• The pilot ports, 5 and 6, are positively sealed from the work ports.
• Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
• Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
