SUN HYDRAULICS
DCDDXXV
$230.93 USD
- SUN HYDRAULICS
- Material:DCDDXXV
- Model:DCDD-XXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCDDXXV (DCDDXXV) is a high-performance hydraulic valve designed for demanding applications requiring robust control and high pressure tolerance. This two-position, detented, 4-way directional cartridge valve features a unique 6-port configuration, allowing for versatile connection setups in hydraulic systems. Each of the ports, including the x and y pilot ports (ports 5 and 6), can withstand pressures up to 5000 psi (350 bar). The DCDDXXV offers three spool options, each influencing the valve\u2019s flow capacity, which ranges between 20 to 30 gpm (80 to 120 L/min). This model is equipped with a hardened spool and sleeve that ensure minimal leakage and superior wear characteristics, essential for maintaining system efficiency and durability. The innovative Sun floating style construction helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing the operational reliability of the valve. Key specifications include a minimum pilot pressure requirement of 150 psi (10.5 bar) to shift the valve, maximum operating pressure of 5000 psi (350 bar), and maximum valve leakage at 110 SUS (24 cSt) of around 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). The DCDDXXV also features pilot volume displacement of approximately .12 in\u00b3 (2.0 cc), a hex size for the valve at 1-1/8 inches (28.6 mm), and an installation torque range of 45-50 lbf\u00b7ft (61-68 Nm). Weighing just .80 lb (0.35 kg), this model is compact yet robust enough for various hydraulic applications. Additionally, it accommodates Viton seals, as specified by the seal kit/cartridge number Viton:990062006, ensuring compatibility with a wide range of fluids and environmental conditions. This makes the Sun Hydraulics DCDDXXV an excellent choice for systems requiring precise control under high-pressure operations.
The Sun Hydraulics DCDDXXV (DCDDXXV) is a high-performance hydraulic valve designed for demanding applications requiring robust control and high pressure tolerance. This two-position, detented, 4-way directional cartridge valve features a unique 6-port configuration, allowing for versatile connection setups in hydraulic systems. Each of the ports, including the x and y pilot ports (ports 5 and 6), can withstand pressures up to 5000 psi (350 bar). The DCDDXXV offers three spool options, each influencing the valve\u2019s flow capacity, which ranges between 20 to 30 gpm (80 to 120 L/min). This model is equipped with a hardened spool and sleeve that ensure minimal leakage and superior wear characteristics, essential for maintaining system efficiency and durability. The innovative Sun floating style construction helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining, enhancing the operational reliability of the valve. Key specifications include a minimum pilot pressure requirement of 150 psi (10.5 bar) to shift the valve, maximum operating pressure of 5000 psi (350 bar), and maximum valve leakage at 110 SUS (24 cSt) of around 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). The DCDDXXV also features pilot volume displacement of approximately .12 in\u00b3 (2.0 cc), a hex size for the valve at 1-1/8 inches (28.6 mm), and an installation torque range of 45-50 lbf\u00b7ft (61-68 Nm). Weighing just .80 lb (0.35 kg), this model is compact yet robust enough for various hydraulic applications. Additionally, it accommodates Viton seals, as specified by the seal kit/cartridge number Viton:990062006, ensuring compatibility with a wide range of fluids and environmental conditions. This makes the Sun Hydraulics DCDDXXV an excellent choice for systems requiring precise control under high-pressure operations.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- The pilot ports, 5 and 6, are positively sealed from the work ports.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-62A |
| Series | 2 |
| Capacity | 20 - 30 gpm80 - 120 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 150 psi10,5 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .12 in³2,0 cc |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .80 lb0,35 kg |
| Seal kit - Cartridge | Viton: 990-062-006 |
