SUN HYDRAULICS
DCEBDCN
$415.79 USD
- SUN HYDRAULICS
- Material:DCEBDCN
- Model:DCEB-DCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCEBDCN (DCEBDCN) is a high-performance, two-position, detented, 4-way directional cartridge valve. This model is designed for heavy-duty hydraulic applications and offers versatility through its multiple spool options which can be configured according to specific operational needs. The DCEBDCN operates with a maximum capacity ranging from 40 to 60 gpm (160 to 240 L/min), making it suitable for a variety of fluid dynamics within hydraulic systems. Engineered for robustness and reliability, the DCEBDCN features hardened spool and sleeve components that ensure low leakage rates and superior wear characteristics. This design enhances the longevity and efficiency of the valve under continuous use conditions. Additionally, the valve incorporates Sun's unique floating style construction which minimizes internal parts binding. This feature addresses potential issues arising from excessive installation torque or variations in cavity/cartridge machining, thereby improving operational stability. The valve supports a maximum operating pressure of 5000 psi (350 bar), including its x and y pilot ports (port 5 and port 6), ensuring it can handle high-pressure applications effortlessly. Each pathway's leakage specifications are meticulously detailed to ensure transparency in performance expectations. The model also includes practical installation features such as a hex size of 1-1/4 inches (31.8 mm) and an installation torque range of 150 to 160 lbf ft (203 to 217 Nm). Weighing at approximately 1.80 lbs (0.80 kg), the DCEBDCN combines lightweight design with robust functionality, making it an ideal choice for sophisticated hydraulic systems requiring precise control over fluid direction and flow.
The Sun Hydraulics DCEBDCN (DCEBDCN) is a high-performance, two-position, detented, 4-way directional cartridge valve. This model is designed for heavy-duty hydraulic applications and offers versatility through its multiple spool options which can be configured according to specific operational needs. The DCEBDCN operates with a maximum capacity ranging from 40 to 60 gpm (160 to 240 L/min), making it suitable for a variety of fluid dynamics within hydraulic systems. Engineered for robustness and reliability, the DCEBDCN features hardened spool and sleeve components that ensure low leakage rates and superior wear characteristics. This design enhances the longevity and efficiency of the valve under continuous use conditions. Additionally, the valve incorporates Sun's unique floating style construction which minimizes internal parts binding. This feature addresses potential issues arising from excessive installation torque or variations in cavity/cartridge machining, thereby improving operational stability. The valve supports a maximum operating pressure of 5000 psi (350 bar), including its x and y pilot ports (port 5 and port 6), ensuring it can handle high-pressure applications effortlessly. Each pathway's leakage specifications are meticulously detailed to ensure transparency in performance expectations. The model also includes practical installation features such as a hex size of 1-1/4 inches (31.8 mm) and an installation torque range of 150 to 160 lbf ft (203 to 217 Nm). Weighing at approximately 1.80 lbs (0.80 kg), the DCEBDCN combines lightweight design with robust functionality, making it an ideal choice for sophisticated hydraulic systems requiring precise control over fluid direction and flow.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-63A |
| Series | 3 |
| Capacity | 40 - 60 gpm160 - 240 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .34 in³5,6 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.80 lb0,80 kg |
| Seal kit - Cartridge | Viton: 990-063-006 |
