SUN HYDRAULICS
DCEBDHV
$435.65 USD
- SUN HYDRAULICS
- Material:DCEBDHV
- Model:DCEB-DHV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCEBDHV (DCEBDHV) is a high-performance, two-position, detented, 4-way directional cartridge valve designed for robust hydraulic system applications. This model boasts a versatile configuration with up to three different spool options available, catering to specific operational requirements. Each unit is capable of handling a maximum operating pressure of 5000 psi (350 bar), and the flow capacity ranges from 40 to 60 gpm (160 to 240 L/min), depending on the spool type specified. The DCEBDHV model features hardened spool and sleeve components that ensure low leakage rates and superior wear characteristics, enhancing the valve's durability and reliability in demanding environments. The innovative Sun floating style construction incorporated into this model minimizes the risk of internal parts binding, which can occur due to excessive installation torque or variations in cavity/cartridge machining. All ports on this valve, including the x and y pilot ports (port 5 and port 6), are designed to accept pressures up to 5000 psi. The maximum valve leakage at 110 SUS (24 cSt) is maintained at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), ensuring efficient operation. Additionally, the pilot volume displacement is rated at .34 in\u00b3 (5.6 cc). For installation, the valve requires a hex size of 1-1/4 inches (31.8 mm) and an installation torque between 150 to 160 lbf\u00b7ft (203 to 217 Nm). The overall weight of the model is approximately 1.80 lbs (0.80 kg). The recommended seal kit for this cartridge is Viton: part number 990063006, ensuring proper maintenance and performance sustainability over time.
The Sun Hydraulics DCEBDHV (DCEBDHV) is a high-performance, two-position, detented, 4-way directional cartridge valve designed for robust hydraulic system applications. This model boasts a versatile configuration with up to three different spool options available, catering to specific operational requirements. Each unit is capable of handling a maximum operating pressure of 5000 psi (350 bar), and the flow capacity ranges from 40 to 60 gpm (160 to 240 L/min), depending on the spool type specified. The DCEBDHV model features hardened spool and sleeve components that ensure low leakage rates and superior wear characteristics, enhancing the valve's durability and reliability in demanding environments. The innovative Sun floating style construction incorporated into this model minimizes the risk of internal parts binding, which can occur due to excessive installation torque or variations in cavity/cartridge machining. All ports on this valve, including the x and y pilot ports (port 5 and port 6), are designed to accept pressures up to 5000 psi. The maximum valve leakage at 110 SUS (24 cSt) is maintained at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), ensuring efficient operation. Additionally, the pilot volume displacement is rated at .34 in\u00b3 (5.6 cc). For installation, the valve requires a hex size of 1-1/4 inches (31.8 mm) and an installation torque between 150 to 160 lbf\u00b7ft (203 to 217 Nm). The overall weight of the model is approximately 1.80 lbs (0.80 kg). The recommended seal kit for this cartridge is Viton: part number 990063006, ensuring proper maintenance and performance sustainability over time.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-63A |
| Series | 3 |
| Capacity | 40 - 60 gpm160 - 240 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .34 in³5,6 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.80 lb0,80 kg |
| Seal kit - Cartridge | Viton: 990-063-006 |
