SUN HYDRAULICS
DCEBXCV
$423.73 USD
- SUN HYDRAULICS
- Material:DCEBXCV
- Model:DCEB-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCEBXCV (DCEBXCV) is a high-performance hydraulic valve designed for robust and precise fluid control in various applications. This two-position, detented, 4-way directional cartridge valve features a six-port configuration that can be tailored with up to three different spool options, depending on specific requirements. Each port, including the x and y pilot ports (port 5 and port 6), can withstand pressures up to 5000 psi (350 bar), ensuring compatibility with high-pressure systems. The DCEBXCV model offers a flow capacity ranging between 40 to 60 gpm (160 to 240 L/min), making it suitable for a variety of flow rates in hydraulic circuits. The maximum valve leakage at 110 SUS (24 cSt) is maintained at approximately 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), highlighting the valve's efficiency in minimizing fluid loss. The pilot volume displacement stands at .34 in\u00b3 (5.6 cc). Key design features include a hardened spool and sleeve which not only reduce spool leakage rates but also enhance wear characteristics, ensuring longevity and consistent performance. The incorporation of Sun\u2019s floating style construction minimizes internal parts binding that might occur due to excessive installation torque or variations in cavity/cartridge machining. This model is engineered for easy installation with a specified hex size of 1\u00bc inches (31.8 mm) and an installation torque range of 150 -160 lbf\u00b7ft (203 -217 Nm). Weighing at approximately 1.80 lbs (0.80 kg), the DCEBXCV maintains a compact and manageable profile for integration into various hydraulic systems without significant weight implications. The seal kit compatible with this cartridge uses Viton material, part number: 990063006, ensuring reliable sealing under diverse operating conditions.
The Sun Hydraulics DCEBXCV (DCEBXCV) is a high-performance hydraulic valve designed for robust and precise fluid control in various applications. This two-position, detented, 4-way directional cartridge valve features a six-port configuration that can be tailored with up to three different spool options, depending on specific requirements. Each port, including the x and y pilot ports (port 5 and port 6), can withstand pressures up to 5000 psi (350 bar), ensuring compatibility with high-pressure systems. The DCEBXCV model offers a flow capacity ranging between 40 to 60 gpm (160 to 240 L/min), making it suitable for a variety of flow rates in hydraulic circuits. The maximum valve leakage at 110 SUS (24 cSt) is maintained at approximately 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), highlighting the valve's efficiency in minimizing fluid loss. The pilot volume displacement stands at .34 in\u00b3 (5.6 cc). Key design features include a hardened spool and sleeve which not only reduce spool leakage rates but also enhance wear characteristics, ensuring longevity and consistent performance. The incorporation of Sun\u2019s floating style construction minimizes internal parts binding that might occur due to excessive installation torque or variations in cavity/cartridge machining. This model is engineered for easy installation with a specified hex size of 1\u00bc inches (31.8 mm) and an installation torque range of 150 -160 lbf\u00b7ft (203 -217 Nm). Weighing at approximately 1.80 lbs (0.80 kg), the DCEBXCV maintains a compact and manageable profile for integration into various hydraulic systems without significant weight implications. The seal kit compatible with this cartridge uses Viton material, part number: 990063006, ensuring reliable sealing under diverse operating conditions.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-63A |
| Series | 3 |
| Capacity | 40 - 60 gpm160 - 240 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .34 in³5,6 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.80 lb0,80 kg |
| Seal kit - Cartridge | Viton: 990-063-006 |
