SUN HYDRAULICS
DCEBXXV
$428.69 USD
- SUN HYDRAULICS
- Material:DCEBXXV
- Model:DCEB-XXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCEBXXV (DCEBXXV) is a two-position, detented, 4-way directional cartridge valve designed for high-pressure hydraulic systems. This model features a 6-port configuration that can be customized with up to three different spool options to suit various application needs. The valve is capable of handling a maximum operating pressure of 5000 psi (350 bar), making it suitable for demanding environments. Each port on the DCEBXXV, including the pilot ports (port 5 and port 6), can accommodate the same high pressure, ensuring versatile connectivity and robust performance in complex hydraulic circuits. The valve's flow capacity ranges between 40 to 60 gpm (160 to 240 L/min), depending on the spool type selected, which allows for flexibility in application scale and scope. Notably, the DCEBXXV incorporates hardened spool and sleeve components that deliver low leakage rates and superior wear characteristics. This durability is further enhanced by Sun Hydraulics' floating style construction, which minimizes internal part binding caused by excessive installation torque or variations in cavity/cartridge machining. The precise engineering of this model ensures consistent operation and longevity in industrial applications. Technical specifications also include a maximum valve leakage at 110 SUS (24 cSt) of approximately 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). Pilot volume displacement stands at .34 in\u00b3 (5.6 cc). For installation, the valve requires a hex size of 1\u00bc inches (31.8 mm) and an installation torque between 150 to 160 lbf\u00b7ft (203 to 217 Nm). The model weighs about 1.80 lb (0.80 kg), making it relatively lightweight yet sturdy for its capabilities. Additionally, it uses Viton seals for enhanced chemical resistance and reliability under various operating conditions.
The Sun Hydraulics DCEBXXV (DCEBXXV) is a two-position, detented, 4-way directional cartridge valve designed for high-pressure hydraulic systems. This model features a 6-port configuration that can be customized with up to three different spool options to suit various application needs. The valve is capable of handling a maximum operating pressure of 5000 psi (350 bar), making it suitable for demanding environments. Each port on the DCEBXXV, including the pilot ports (port 5 and port 6), can accommodate the same high pressure, ensuring versatile connectivity and robust performance in complex hydraulic circuits. The valve's flow capacity ranges between 40 to 60 gpm (160 to 240 L/min), depending on the spool type selected, which allows for flexibility in application scale and scope. Notably, the DCEBXXV incorporates hardened spool and sleeve components that deliver low leakage rates and superior wear characteristics. This durability is further enhanced by Sun Hydraulics' floating style construction, which minimizes internal part binding caused by excessive installation torque or variations in cavity/cartridge machining. The precise engineering of this model ensures consistent operation and longevity in industrial applications. Technical specifications also include a maximum valve leakage at 110 SUS (24 cSt) of approximately 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). Pilot volume displacement stands at .34 in\u00b3 (5.6 cc). For installation, the valve requires a hex size of 1\u00bc inches (31.8 mm) and an installation torque between 150 to 160 lbf\u00b7ft (203 to 217 Nm). The model weighs about 1.80 lb (0.80 kg), making it relatively lightweight yet sturdy for its capabilities. Additionally, it uses Viton seals for enhanced chemical resistance and reliability under various operating conditions.
Two-position, detented, 4-way directional cartridges are 6-port directional valves that can be configured with up to 3 different spool options. The supply port is port 1 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 5 and port 6).
- Leakage listed in technical data is for each path.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-63A |
| Series | 3 |
| Capacity | 40 - 60 gpm160 - 240 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .34 in³5,6 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.80 lb0,80 kg |
| Seal kit - Cartridge | Viton: 990-063-006 |
