SUN HYDRAULICS
DCFAXBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DCFAXBV (DCFAXBV) is a versatile hydraulic valve designed for high-pressure applications, capable of handling pressures up to 5000 psi (350 bar). This three-position, 4-way directional cartridge valve is spring-centered and features six ports, including X and Y pilot ports. It offers a variety of configurations with 10 different spool options available, allowing it to meet diverse operational requirements. The valve\u2019s capacity ranges from 50 to 200 gpm (200 to 760 L/min), depending on the spool type selected. Engineered for reliability and performance, the DCFAXBV incorporates hardened spool and sleeve components that ensure low leakage rates and superior wear characteristics. This model also benefits from Sun Hydraulics' floating style construction, which reduces the risk of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. The minimum pilot pressure required to shift the valve is 125 psi (9 bar), and it features a maximum valve leakage at 110 SUS (24 cSt) of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). Additional technical specifications include a pilot volume displacement of .42 in\u00b3 (6.9 cc), a valve hex size of 1-5/8 inches (41.3 mm), and an installation torque range of 350-375 lbf\u00b7ft (474-508 Nm). The model weighs approximately 3.80 lb (1.75 kg). For maintenance or repairs, a Viton seal kit/cartridge is available under part number 990064006. This robust design and flexible configuration make the DCFAXBV suitable for a wide range of hydraulic systems where precise flow control and high-pressure capability are required.
