SUN HYDRAULICS
DDDCXDV
$221.70 USD
- SUN HYDRAULICS
- Material:DDDCXDV
- Model:DDDC-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDDCXDV (DDDCXDV) is a high-performance three-position, 4-way directional cartridge valve designed for robust hydraulic system applications. This valve features a spring-centered mechanism and includes six ports with the ability to handle up to 5000 psi (350 bar), making it suitable for heavy-duty operations. The DDDCXDV model is tailored with a hardened spool and sleeve which not only ensure low leakage rates but also contribute to outstanding wear characteristics, enhancing the valve's durability and reliability in demanding environments. Equipped with Sun\u2019s floating style construction, the DDDCXDV minimizes internal parts binding which could be caused by excessive installation torque or variations in cavity/cartridge machining. This feature aids in maintaining consistent performance even under variable operational conditions. The valve operates within a capacity of 20 gpm (80 L/min) and requires a minimum pilot pressure of 150 psi (10.5 bar) to shift effectively. It also supports a maximum operating pressure of 5000 psi (350 bar), with maximum leakage at 110 SUS 24 cSt maintained at about 2 in\u00b3/min per 1000 psi (30 cc/min per 70 bar). Additional technical specifications include pilot volume displacement at approximately 0.05 in\u00b3 (0.82 cc), and the valve\u2019s hex size is measured at 1-1/8 inches (28.6 mm). For installation, the recommended torque is between 45 \u2013 50 lbf\u00b7ft (61 \u2013 68 Nm). The DDDCXDV utilizes Viton seals for enhanced fluid compatibility and temperature resilience, ensuring reliable sealing under varied environmental conditions.
The Sun Hydraulics DDDCXDV (DDDCXDV) is a high-performance three-position, 4-way directional cartridge valve designed for robust hydraulic system applications. This valve features a spring-centered mechanism and includes six ports with the ability to handle up to 5000 psi (350 bar), making it suitable for heavy-duty operations. The DDDCXDV model is tailored with a hardened spool and sleeve which not only ensure low leakage rates but also contribute to outstanding wear characteristics, enhancing the valve's durability and reliability in demanding environments. Equipped with Sun\u2019s floating style construction, the DDDCXDV minimizes internal parts binding which could be caused by excessive installation torque or variations in cavity/cartridge machining. This feature aids in maintaining consistent performance even under variable operational conditions. The valve operates within a capacity of 20 gpm (80 L/min) and requires a minimum pilot pressure of 150 psi (10.5 bar) to shift effectively. It also supports a maximum operating pressure of 5000 psi (350 bar), with maximum leakage at 110 SUS 24 cSt maintained at about 2 in\u00b3/min per 1000 psi (30 cc/min per 70 bar). Additional technical specifications include pilot volume displacement at approximately 0.05 in\u00b3 (0.82 cc), and the valve\u2019s hex size is measured at 1-1/8 inches (28.6 mm). For installation, the recommended torque is between 45 \u2013 50 lbf\u00b7ft (61 \u2013 68 Nm). The DDDCXDV utilizes Viton seals for enhanced fluid compatibility and temperature resilience, ensuring reliable sealing under varied environmental conditions.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-52A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 150 psi10,5 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-052-006 |
