SUN HYDRAULICS
DDDCXRN
$205.81 USD
- SUN HYDRAULICS
- Material:DDDCXRN
- Model:DDDC-XRN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDDCXRN (DDDCXRN) is a high-performance hydraulic valve characterized by its three-position, 4-way directional configuration. This model is spring-centered and features a 6-port directional valve setup that can be tailored with various spool options to meet specific application needs. The DDDCXRN operates effectively with a maximum capacity of 20 gpm (80 L/min) and can withstand pressures up to 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6). Designed for robustness and reliability, the valve features hardened spool and sleeve components that ensure low leakage rates and superior wear resistance. The incorporation of Sun's floating style construction minimizes internal parts binding, which could otherwise result from excessive installation torque or machining variations in cavity-cartridge setups. This model requires a minimum pilot pressure of 150 psi (10.5 bar) to shift the valve, ensuring precise control in various hydraulic systems. Additional specifications include a maximum valve leakage at 110 SUS (24 cSt) of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), pilot volume displacement of .05 in\u00b3 (0.82 cc), and an installation torque requirement between 45 - 50 lbf\u00b7ft (61 - 68 Nm). The DDDCXRN uses Viton seals for enhanced performance under varying conditions, ensuring long-term durability and minimal maintenance requirements. This model employs T52A cavity specifications and belongs to the Series 2 line of Sun Hydraulics' products, making it compatible with a wide range of industrial applications requiring precise fluid control.
The Sun Hydraulics DDDCXRN (DDDCXRN) is a high-performance hydraulic valve characterized by its three-position, 4-way directional configuration. This model is spring-centered and features a 6-port directional valve setup that can be tailored with various spool options to meet specific application needs. The DDDCXRN operates effectively with a maximum capacity of 20 gpm (80 L/min) and can withstand pressures up to 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6). Designed for robustness and reliability, the valve features hardened spool and sleeve components that ensure low leakage rates and superior wear resistance. The incorporation of Sun's floating style construction minimizes internal parts binding, which could otherwise result from excessive installation torque or machining variations in cavity-cartridge setups. This model requires a minimum pilot pressure of 150 psi (10.5 bar) to shift the valve, ensuring precise control in various hydraulic systems. Additional specifications include a maximum valve leakage at 110 SUS (24 cSt) of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), pilot volume displacement of .05 in\u00b3 (0.82 cc), and an installation torque requirement between 45 - 50 lbf\u00b7ft (61 - 68 Nm). The DDDCXRN uses Viton seals for enhanced performance under varying conditions, ensuring long-term durability and minimal maintenance requirements. This model employs T52A cavity specifications and belongs to the Series 2 line of Sun Hydraulics' products, making it compatible with a wide range of industrial applications requiring precise fluid control.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-52A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 150 psi10,5 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-052-006 |
