SUN HYDRAULICS
DDDCXRV
$216.73 USD
- SUN HYDRAULICS
- Material:DDDCXRV
- Model:DDDC-XRV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDDCXRV (DDDCXRV) is a versatile and robust three-position, 4-way directional cartridge valve, engineered to function in a variety of hydraulic applications. This model features a spring-centered mechanism and includes six ports with the capacity to handle pressures up to 5000 psi (350 bar). The DDDCXRV spool options allow customization based on specific operational requirements, enhancing its utility across different scenarios. Key specifications include a maximum flow capacity of 20 gpm (80 L/min), and the valve requires a minimum pilot pressure of 150 psi (10.5 bar) for shifting. It offers remarkably low leakage rates\u20142 in\u00b3/min at 1000 psi (30 cc/min at 70 bar)\u2014thanks to its hardened spool and sleeve design which also contributes to outstanding wear characteristics and consistent performance. This model is designed using Sun's floating style construction which minimizes internal parts binding, a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The valve features a hex size of 1-1/8 inches (28.6 mm) and an installation torque range between 45 - 50 lbf\u00b7ft (61 - 68 Nm), ensuring easy installation while maintaining reliability and durability. The DDDCXRV operates efficiently under maximum operating pressures of up to 5000 psi (350 bar), making it suitable for high-pressure applications. Its design incorporates Viton seals for enhanced performance under various environmental conditions. This model is housed in a T52A cavity and belongs to the Series 2 line of Sun Hydraulics\u2019 products, ensuring compatibility with a wide range of hydraulic systems.
The Sun Hydraulics DDDCXRV (DDDCXRV) is a versatile and robust three-position, 4-way directional cartridge valve, engineered to function in a variety of hydraulic applications. This model features a spring-centered mechanism and includes six ports with the capacity to handle pressures up to 5000 psi (350 bar). The DDDCXRV spool options allow customization based on specific operational requirements, enhancing its utility across different scenarios. Key specifications include a maximum flow capacity of 20 gpm (80 L/min), and the valve requires a minimum pilot pressure of 150 psi (10.5 bar) for shifting. It offers remarkably low leakage rates\u20142 in\u00b3/min at 1000 psi (30 cc/min at 70 bar)\u2014thanks to its hardened spool and sleeve design which also contributes to outstanding wear characteristics and consistent performance. This model is designed using Sun's floating style construction which minimizes internal parts binding, a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The valve features a hex size of 1-1/8 inches (28.6 mm) and an installation torque range between 45 - 50 lbf\u00b7ft (61 - 68 Nm), ensuring easy installation while maintaining reliability and durability. The DDDCXRV operates efficiently under maximum operating pressures of up to 5000 psi (350 bar), making it suitable for high-pressure applications. Its design incorporates Viton seals for enhanced performance under various environmental conditions. This model is housed in a T52A cavity and belongs to the Series 2 line of Sun Hydraulics\u2019 products, ensuring compatibility with a wide range of hydraulic systems.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-52A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 150 psi10,5 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-052-006 |
