SUN HYDRAULICS
DDDCXYV
$211.77 USD
- SUN HYDRAULICS
- Material:DDDCXYV
- Model:DDDC-XYV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDDCXYV (Material Number DDDCXYV) is a high-performance hydraulic valve that offers robust control for various fluid power applications. This three-position, 4-way directional cartridge valve is spring-centered and features a 6-port configuration, allowing for flexible installation and operation. It is specifically designed to handle a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure systems. The valve's capacity varies depending on the spool type specified, with a general flow capacity of up to 20 gpm (80 L/min). It requires a minimum pilot pressure of 150 psi (10.5 bar) to shift, ensuring reliable operation under varying conditions. The DDDCXYV includes hardened spool and sleeve components that not only reduce leakage but also enhance wear characteristics, contributing to the longevity and reliability of the system. Incorporating Sun\u2019s floating style construction, this valve minimizes internal parts binding which could otherwise occur due to excessive installation torque or variations in cavity/cartridge machining. This feature ensures consistent performance even under challenging installation conditions. The valve's design also facilitates easy maintenance with available Viton seal kits (part number 990052006), ensuring sustained performance through prolonged use. The DDDCXYV is equipped with a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm), making it straightforward to install while maintaining secure fitting in its cavity type T52A from series 2. With its robust design and versatile specifications, the Sun Hydraulics DDDCXYV valve stands out as a reliable component in any hydraulic system requiring precise direction control under high pressure.
The Sun Hydraulics DDDCXYV (Material Number DDDCXYV) is a high-performance hydraulic valve that offers robust control for various fluid power applications. This three-position, 4-way directional cartridge valve is spring-centered and features a 6-port configuration, allowing for flexible installation and operation. It is specifically designed to handle a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure systems. The valve's capacity varies depending on the spool type specified, with a general flow capacity of up to 20 gpm (80 L/min). It requires a minimum pilot pressure of 150 psi (10.5 bar) to shift, ensuring reliable operation under varying conditions. The DDDCXYV includes hardened spool and sleeve components that not only reduce leakage but also enhance wear characteristics, contributing to the longevity and reliability of the system. Incorporating Sun\u2019s floating style construction, this valve minimizes internal parts binding which could otherwise occur due to excessive installation torque or variations in cavity/cartridge machining. This feature ensures consistent performance even under challenging installation conditions. The valve's design also facilitates easy maintenance with available Viton seal kits (part number 990052006), ensuring sustained performance through prolonged use. The DDDCXYV is equipped with a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 \u2013 50 lbf ft (61 \u2013 68 Nm), making it straightforward to install while maintaining secure fitting in its cavity type T52A from series 2. With its robust design and versatile specifications, the Sun Hydraulics DDDCXYV valve stands out as a reliable component in any hydraulic system requiring precise direction control under high pressure.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-52A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 150 psi10,5 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-052-006 |
