SUN HYDRAULICS
DDDGXCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDDGXCV (Material Number: DDDGXCV) is a two-position, 3-way directional cartridge valve designed for high-performance hydraulic systems. This model features a six-port configuration, although port 5 is not utilized, allowing for versatile plumbing options. The primary supply port is designated as port 3, and all ports are capable of withstanding pressures up to 5000 psi (350 bar). The DDDGXCV can be customized with up to five different spool configurations, each influencing the valve's capacity and pilot pressure requirements. This valve's operational capacity reaches up to 20 gpm (80 L/min), with a minimum pilot pressure requirement of 145 psi (10 bar) for shifting. To achieve a full shift at the rated flow, a pilot pressure of 290 psi (20 bar) is necessary. The valve's design incorporates hardened spool and sleeve components to ensure low leakage rates and superior wear characteristics over time. Additionally, it features Sun\u2019s floating style construction which minimizes internal parts binding\u2014a common issue stemming from excessive installation torque or variations in cavity/cartridge machining. Other technical specifics include a maximum leakage rate of 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar), pilot volume displacement of approximately 0.05 in\u00b3 (0.82 cc), and an installation torque requirement between 45 \u2013 50 lbf\u00b7ft (61 \u2013 68 Nm). The valve also uses Viton seals for enhanced performance under various operating conditions. With its robust design and flexible configuration options, the Sun Hydraulics DDDGXCV is well-suited for applications requiring reliable directional control in hydraulic circuits.
